Data Dictionary, Full Field Reference

Every table Cordelia creates in your SQLite database, and every column in it: 124 tables, 1635 fields.

Generated from Cordelia's own source code: every table and column name below is the literal SQL Cordelia executes, and every description is that field's documentation comment.

Every table also has a RecordNumber integer primary key column, added automatically by Cordelia and not part of the FIT data itself, so it is omitted from the per-table lists below since it's the same on every table.

Tables

AadAccelFeatures
AccelerometerData
Activity
AntChannelId
AntRx
AntTx
AviationAttitude
BarometerData
BeatIntervals
BikeProfile
BloodPressure
CadenceZone
CameraEvent
Capabilities
ChronoShotData
ChronoShotSession
ClimbPro
Connectivity
Course
CoursePoint
DeveloperCIQFields
DeveloperDataId
DeviceAuxBatteryInfo
DeviceInfo
DeviceSettings
DiveAlarm
DiveApneaAlarm
DiveGas
DiveSettings
DiveSummary
Event
ExdDataConceptConfiguration
ExdDataFieldConfiguration
ExdScreenConfiguration
ExerciseTitle
FieldCapabilities
FieldDescription
FileCapabilities
FileCreator
FileID
Goal
GpsMetadata
GyroscopeData
Hr
HrmProfile
Hrv
HrvStatusSummary
HrvValue
HrZone
HsaAccelerometerData
HsaBodyBatteryData
HsaConfigurationData
HsaEvent
HsaGyroscopeData
HsaHeartRateData
HsaRespirationData
HsaSpo2Data
HsaStepData
HsaStressData
HsaWristTemperatureData
Jump
Lap
Length
MagnetometerData
MaxMetData
MemoGlob
MesgCapabilities
MetZone
Monitoring
MonitoringHrData
MonitoringInfo
NapEvent
NmeaSentence
ObdiiData
OhrSettings
OneDSensorCalibration
PowerZone
RawBbi
Record
RespirationRate
Schedule
SdmProfile
SegmentFile
SegmentId
SegmentLap
SegmentLeaderboardEntry
SegmentPoint
Session
SetX
SkinTempOvernight
SlaveDevice
SleepAssessment
SleepDisruptionOvernightSeverity
SleepDisruptionSeverityPeriod
SleepLevel
Software
SpeedZone
Split
SplitSummary
Spo2Data
Sport
StressLevel
TankSummary
TankUpdate
ThreeDSensorCalibration
TimeInZone
TimestampCorrelation
Totals
TrainingFile
TrainingSettings
UserProfile
Video
VideoClip
VideoDescription
VideoFrame
VideoTitle
WatchfaceSettings
WeatherAlert
WeatherConditions
WeightScale
Workout
WorkoutSession
WorkoutStep
ZonesTarget

AadAccelFeatures

Number of accelerometer zero crossings summed over the specified time interval.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`time`	INTEGER	Time interval length in seconds.
`energy_total`	INTEGER	Total accelerometer energy in the interval.
`zero_cross_cnt`	INTEGER	Count of zero crossings.
`instance`	INTEGER	Instance ID of zero crossing algorithm.
`time_above_threshold`	REAL	Total accelerometer time above the threshold in the interval. Units: s.

AccelerometerData

contains raw and calibrated accelerometer sensor readings.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`sample_time_offset`	TEXT	Each time in the array describes the time, in milliseconds, at which the accelerometer sample with the corresponding index was taken. Limited to 30 samples per message; the samples may span across seconds. Array size must match the number of samples in accel_x, accel_y, and accel_z.One value per sample, index-aligned with accel_x/accel_y/accel_z.
`accel_x`	TEXT	these are the raw ADC reading. The maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`accel_y`	TEXT	these are the raw ADC reading. The maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`accel_z`	TEXT	these are the raw ADC reading. The maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`calibrated_accel_x`	TEXT	calibrated X acceleration reading. Units: g.One value per sample, index-aligned with sample_time_offset.
`calibrated_accel_y`	TEXT	calibrated Y acceleration reading. Units: g.One value per sample, index-aligned with sample_time_offset.
`calibrated_accel_z`	TEXT	calibrated Z acceleration reading. Units: g.One value per sample, index-aligned with sample_time_offset.
`compressed_calibrated_accel_x`	TEXT	calibrated X acceleration reading. Units: mG.One value per sample, index-aligned with sample_time_offset.
`compressed_calibrated_accel_y`	TEXT	calibrated Y acceleration reading. Units: mG.One value per sample, index-aligned with sample_time_offset.
`compressed_calibrated_accel_z`	TEXT	calibrated Z acceleration reading. Units: mG.One value per sample, index-aligned with sample_time_offset.

Activity

Summarizes an entire activity session including duration, distance, and performance metrics.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`total_timer_time`	REAL	Total time taken, excluding pauses. Units: s.
`number_sessions`	INTEGER	Number of Sessions.
`type`	INTEGER	Activity type.
`event_id`	INTEGER	FIT event code identifying what triggered this record, such as a timer start/stop or a lap marker.
`event_type`	INTEGER	FIT event-type code describing how the event occurred, such as start, stop, or marker.
`local_timestamp`	TEXT	Timestamp epoch expressed in local time, in ISO8601 format. Used to convert activity timestamps to local time.
`event_group`	INTEGER	Groups related events together, distinguishing concurrent event streams (such as separate segments within a multisport session) that share the same event_id and event_type.

AntChannelId

Identifies which ANT+ sensor device is paired to a specific ANT channel.

Field	Type	Description
`file_number`	INTEGER	The file number.
`channel_number`	INTEGER	ANT channel number used for this transmission.
`device_type`	INTEGER	Device Type,.
`device_number`	INTEGER	Numeric ANT device ID of the specific sensor paired on this channel.
`transmission_type`	INTEGER	Transmission Type,.
`device_index`	INTEGER	Device Index,.

AntRx

Ant Rx message data.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`fractional_timestamp`	REAL	Fractional-second part of the timestamp, in seconds.
`message_id`	INTEGER	ANT message ID identifying the type of this raw ANT message.
`message_data`	TEXT	Raw ANT message payload bytes.One byte per element, in the order received in the raw ANT message payload.
`channel_number`	INTEGER	ANT channel number used for this transmission.
`data`	TEXT	Raw bytes of the received ANT+ message.One byte per element, in the order received in the raw ANT+ message.

AntTx

Ant TX record.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`fractional_timestamp`	REAL	Fractional milliseconds part of timestamp.
`message_id`	INTEGER	ANT message ID identifying the type of this raw ANT message.
`message_data`	TEXT	Raw ANT message payload bytes.One byte per element, in the order received in the raw ANT message payload.
`channel_number`	INTEGER	ANT channel number used for this transmission.
`data`	TEXT	Raw bytes of the transmitted ANT+ message.One byte per element, in the order transmitted in the raw ANT+ message.

AviationAttitude

contains flight attitude data including pitch, roll, and heading.

Field	Type	Description
`file_number`	INTEGER	The source FIT file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`system_time`	TEXT	System time associated with the sample expressed in milliseconds.One value per attitude sample in this message.
`pitch`	TEXT	Pitch in radians.One value per attitude sample, index-aligned with system_time.
`roll`	TEXT	Roll in radians.One value per attitude sample, index-aligned with system_time.
`accel_lateral`	TEXT	Lateral acceleration. Units: m/s^2; scale: 100; Range -78.4 to +78.4 (-8 Gs to 8 Gs).One value per attitude sample, index-aligned with system_time.
`accel_normal`	TEXT	Normal acceleration. Units: m/s^2; scale: 100; Range -78.4 to +78.4 (-8 Gs to 8 Gs).One value per attitude sample, index-aligned with system_time.
`turn_rate`	TEXT	Turn rate. Units: radians/second; scale: 1024; Range -8.727 to +8.727 (-500 degs/sec to +500 degs/sec).One value per attitude sample, index-aligned with system_time.
`stage`	TEXT	Flight stage during which this attitude reading was recorded.One value per attitude sample, index-aligned with system_time.
`attitude_stage_complete`	TEXT	Attitude stage complete. Units: %; The percent complete of the current attitude stage. Set to 0 for attitude stages 0, 1, and 2 and to 100 for attitude stage 3 by AHRS modules that do not support it. Range - 100.One value per attitude sample, index-aligned with system_time.
`track`	TEXT	Track. Units: radians; scale: 10430.38; Track Angle/Heading Range 0 - 2pi.One value per attitude sample, index-aligned with system_time.
`validity`	TEXT	Whether this attitude reading is valid.One value per attitude sample, index-aligned with system_time.

BarometerData

contains raw barometric pressure readings.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`sample_time_offset`	TEXT	Each time in the array describes the time, in milliseconds, at which the barometer sample with the corresponding index was taken. The samples may span across seconds. Array size must match the number of samples in barometric_pressure.One value per sample, index-aligned with barometric_pressure.
`barometric_pressure`	TEXT	Barometric pressure. Units: Pa; These are the raw ADC reading. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.

BeatIntervals

Array of heart beat intervals.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`time`	TEXT	Array of millisecond times between beats.One value per successive heartbeat interval, in chronological order.

BikeProfile

contains bike-specific settings including sensors, wheel size, and calibration data.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`bike_profile_name`	TEXT	User-assigned name for this bike profile.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`odometer`	REAL	In metres.
`bike_spd_ant_id`	INTEGER	Bike Speed ANT ID.
`bike_cad_ant_id`	INTEGER	Bike Cadence ANT ID.
`bike_spdcad_ant_id`	INTEGER	ANT device ID of the combined speed/cadence sensor paired with this bike.
`bike_power_ant_id`	INTEGER	ANT device ID of the power meter paired with this bike.
`custom_wheelsize`	REAL	Custom wheel size in centimeters.
`auto_wheelsize`	REAL	Automatic wheel size. Units: m.
`bike_weight`	REAL	Weight of the bike in kilograms.
`power_cal_factor`	REAL	Power calculation factor. Units: %.
`auto_wheel_cal`	INTEGER	Whether wheel circumference is calibrated automatically rather than using custom_wheelsize.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`auto_power_zero`	INTEGER	Whether the power meter zero-offset is calibrated automatically.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`id`	INTEGER	Identifier of this bike profile.
`spd_enabled`	INTEGER	Speed Enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`cad_enabled`	INTEGER	Cadence Enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`spdcad_enabled`	INTEGER	Whether the combined speed/cadence sensor is enabled for this bike.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`power_enabled`	INTEGER	Whether the power meter is enabled for this bike.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`crank_length`	REAL	Crank length. offset: -110.
`enabled`	INTEGER	Whether this bike profile is enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`bike_spd_ant_id_trans_type`	INTEGER	Bike Speed ANT ID Trans Type.
`bike_cad_ant_id_trans_type`	INTEGER	Bike Cadence ANT ID Trans Type.
`bike_spdcad_ant_id_trans_type`	INTEGER	ANT transmission type of the combined speed/cadence sensor identified by bike_spdcad_ant_id.
`bike_power_ant_id_trans_type`	INTEGER	ANT transmission type of the power meter identified by bike_power_ant_id.
`odometer_rollover`	INTEGER	Rollover counter that can be used to extend the odometer.
`front_gear_number`	INTEGER	Number of front gears.
`front_gear`	TEXT	Number of teeth on each gear 0 is innermost.One value per gear; index 0 is the innermost gear.
`rear_gear_number`	INTEGER	Number of rear gears.
`rear_gear`	TEXT	Number of teeth on each gear 0 is innermost.One value per gear; index 0 is the innermost gear.
`shimano_di2_enabled`	INTEGER	Shimano Di 2 Enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.

BloodPressure

Blood pressure readings taken by a connected blood-pressure monitor.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`systolic_pressure`	INTEGER	Systolic blood pressure in millimeters of mercury.
`diastolic_pressure`	INTEGER	Diastolic blood pressure in millimeters of mercury.
`mean_arterial_pressure`	INTEGER	Mean arterial pressure in millimeters of mercury.
`map3_sample_mean`	INTEGER	Map sample mean.
`map_morning_values`	INTEGER	Morning values. Units: mmHg.
`map_evening_values`	INTEGER	Evening values. Units: mmHg.
`heart_rate`	INTEGER	Heart rate in beats per minute.
`heart_rate_type`	INTEGER	Method used to measure heart rate for this reading, such as from a paired sensor or an estimate.
`status`	INTEGER	Status of the blood pressure reading, such as valid or error.
`user_profile_index`	INTEGER	Associates this blood pressure message to a user. This corresponds to the index of the user profile message in the blood pressure file.

CadenceZone

Defines cadence training zones.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`high_value`	INTEGER	Upper boundary of this cadence zone, in revolutions per minute.
`Name`	TEXT	User-assigned name for this cadence zone.

CameraEvent

Records events related to camera usage during an activity.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`camera_event_type`	INTEGER	FIT event code identifying what camera action occurred, such as capture start or capture end.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`camera_file_uuid`	TEXT	Unique identifier of the camera file (photo or video) associated with this event.
`camera_orientation`	INTEGER	Orientation of the camera at the time of this event.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

Capabilities

Describes supported languages, sports, and connectivity features of the device.

Field	Type	Description
`file_number`	INTEGER	The file number.
`languages`	TEXT	Use language_bits_x types where x is index of array.One bitmask byte per language_bits_x index, x being the element's position in this array.
`sports`	TEXT	Use sport_bits_x types where x is index of array.One bitmask byte per sport_bits_x index, x being the element's position in this array.
`workouts_supported`	INTEGER	Bitmask of workout_capabilities flags describing which workout step types this device supports.
`connectivity_supported`	INTEGER	Bitmask of connectivity_capabilities flags describing which wireless connectivity features this device supports.

ChronoShotData

Individual projectile-speed reading for one shot, as measured by a Garmin XERO chronograph device.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`shot_speed`	REAL	Projectile speed in meters per second.
`shot_number`	INTEGER	Index identifying this shot within the chrono shot session.

ChronoShotSession

Summary statistics (min/max/average speed, shot count) for a shooting session recorded by a Garmin XERO chronograph device.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`min_speed`	REAL	Minimum speed. Units: m/s.
`max_speed`	REAL	Maximum speed. Units: m/s.
`avg_speed`	REAL	Average speed. Units: m/s.
`shot_count`	INTEGER	Total number of shots recorded in this session.
`projectile_type`	INTEGER	Type of projectile measured, such as arrow or bullet.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`grain_weight`	REAL	Projectile weight in grains.
`standard_deviation`	REAL	Standard deviation of shot speed, in meters per second.

ClimbPro

Climb Pro record.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`position_lat`	INTEGER	Position latitude. Units: semicircles.
`position_long`	INTEGER	Position longitude. Units: semicircles.
`climb_pro_event`	INTEGER	FIT event code identifying the ClimbPro state change, such as climb start or climb complete.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`climb_number`	INTEGER	Index identifying which climb (in a sequence of climbs on the course) this event pertains to.
`climb_category`	INTEGER	Difficulty category assigned to this climb, such as by length and grade.
`current_dist`	REAL	Current distance. Units: m.

Connectivity

Defines wireless and network connectivity options such as Bluetooth and ANT+.

Field	Type	Description
`file_number`	INTEGER	The file number.
`bluetooth_enabled`	INTEGER	Use Bluetooth for connectivity features.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`bluetooth_le_enabled`	INTEGER	Use Bluetooth Low Energy for connectivity features.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`ant_enabled`	INTEGER	Use ANT for connectivity features.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`Name`	TEXT	Name of the paired companion app or service providing connectivity.
`live_tracking_enabled`	INTEGER	Whether live tracking (sharing real-time location with others) is enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`weather_conditions_enabled`	INTEGER	Whether current weather conditions can be downloaded to the device.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`weather_alerts_enabled`	INTEGER	Whether severe weather alerts can be downloaded to the device.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`auto_activity_upload_enabled`	INTEGER	Whether completed activities are automatically uploaded to the companion app.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`course_download_enabled`	INTEGER	Whether courses can be downloaded to the device from the companion app.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`workout_download_enabled`	INTEGER	Whether workouts can be downloaded to the device from the companion app.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`gps_ephemeris_download_enabled`	INTEGER	Whether GPS ephemeris data (for faster satellite fix) can be downloaded to the device.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`incident_detection_enabled`	INTEGER	Whether incident detection (automatically alerting contacts after a suspected fall or crash) is enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`grouptrack_enabled`	INTEGER	Whether GroupTrack (sharing live location with other paired devices in the same group) is enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.

Course

Record.

Field	Type	Description
`file_number`	INTEGER	The file number.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`Name`	TEXT	User-assigned name for this course.
`capabilities_id`	INTEGER	Bitmask of course_capabilities flags describing which optional data types (such as heart rate or power) this course includes.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

CoursePoint

Course Point record.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`timestamp`	TEXT	In ISO8601 format.
`position_lat`	INTEGER	Latitude position. Units: semicircles.
`position_long`	INTEGER	Longitude position. Units: semicircles.
`distance`	REAL	Distance from the start of the course to this point, in meters.
`type`	INTEGER	Type of course point, such as summit, water station, or danger.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`Name`	TEXT	User-assigned or generated name for this course point.
`favorite`	INTEGER	Whether this course point is marked as a favorite.Stored in SQLite as INTEGER: 0 = false, 1 = true.

DeveloperCIQFields

a single Developer/CIQ field value attached to a native message row (Record/Lap/Session). Generic storage for dynamic, app-defined FIT developer fields -- see docs/notes/fit-import-gaps-plan-2026-07-03.md section 3b for the schema rationale.

Field	Type	Description
`file_number`	INTEGER	The file number.
`table_attached_to`	TEXT	Which native table key_into_attached_table refers to (e.g. "Record").
`key_into_attached_table`	INTEGER	The native row's own real primary key.
`developer_data_index`	INTEGER	Correlates to DeveloperDataId.developer_data_index.
`field_definition_number`	INTEGER	Correlates to FieldDescription.field_definition_number.
`field_type`	INTEGER	0=Unknown, 1=INTEGER, 2=REAL, 3=INTEGER VECTOR, 4=REAL VECTOR, 5=STRING, 6=STRING VECTOR -- see the FieldTypeLookup table for the code-to-description mapping.
`field_value_numeric`	REAL	Populated only when field_type is 1 (INTEGER) or 2 (REAL); NULL in the database otherwise.
`field_as_text`	TEXT	Populated only when field_type is 3, 4, 5, or 6 (any vector type or STRING), via the same bind_numeric_array/bind_string_array encoding used for native vector<T> fields; NULL in the database otherwise.

DeveloperDataId

Developer_data_id: Must be logged before field description.

Field	Type	Description
`file_number`	INTEGER	The file number.
`developer_id`	TEXT	Unique identifier of the developer or company that created this custom data source.One byte per element of this single identifier, not one value per sample.
`application_id`	TEXT	Unique identifier of the specific application that created this custom data source.One byte per element of this single identifier, not one value per sample.
`manufacturer_id`	INTEGER	FIT manufacturer code identifying the device maker, such as Garmin or a third-party partner.
`developer_data_index`	INTEGER	Index uniquely identifying this developer data source within the file; FieldDescription entries reference this value via their own developer_data_index field.
`application_version`	INTEGER	Version number of the application identified by application_id.

DeviceAuxBatteryInfo

Provides information about auxiliary batteries connected to the device.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`device_index`	INTEGER	Index identifying which connected device this data pertains to, matching a device_info record's own device_index.
`battery_voltage`	REAL	Battery voltage in volts.
`battery_status`	INTEGER	Battery charge-level bucket, such as new, good, ok, low, or critical.
`battery_identifier`	INTEGER	Identifies which of the device's auxiliary batteries this reading is for, when a device has more than one.

DeviceInfo

Provides details about connected devices including manufacturer, serial number, and battery status.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`device_index`	INTEGER	Index uniquely identifying this device within the file; other messages reference this value via their own device_index field to indicate which device produced their data.
`device_type`	INTEGER	Manufacturer-specific device-type code for this device; interpreted using its own manufacturer_id/garmin_product_id.
`ble_device_type`	INTEGER	Device-type code as reported over Bluetooth Low Energy.
`antplus_device_type`	INTEGER	ANT+ Device Type.
`ant_device_type`	INTEGER	Device-type code as reported over ANT.
`local_device_type`	INTEGER	Locally-assigned device-type code, used for devices without a standard ANT/BLE device-type code.
`manufacturer_id`	INTEGER	FIT manufacturer code identifying the device maker, such as Garmin or a third-party partner.
`serial_number`	INTEGER	Serial number of the device, when available.
`product_id`	INTEGER	Manufacturer-specific product code identifying the device model; interpreted via garmin_product_id or favero_product_id when the manufacturer defines its own product-code table.
`favero_product_id`	INTEGER	Favero-specific product code identifying the device model, valid only when manufacturer_id is Favero Electronics.
`garmin_product_id`	INTEGER	Garmin-specific product code identifying the device model, valid only when manufacturer_id is Garmin.
`software_version`	REAL	Software or firmware version installed on the device.
`hardware_version`	INTEGER	Hardware revision number of the device.
`cumulative_operating_time`	INTEGER	Cumulative operating time, in seconds.
`battery_voltage`	REAL	Battery voltage in volts.
`battery_status`	INTEGER	Battery charge-level bucket, such as new, good, ok, low, or critical.
`sensor_position`	INTEGER	Indicates the location of the sensor.
`descriptor`	TEXT	Used to describe the sensor or location.
`ant_transmission_type`	INTEGER	ANT transmission type of this device, paired with ant_device_number to uniquely identify it on the ANT network.
`ant_device_number`	INTEGER	ANT device number of this device, paired with ant_transmission_type to uniquely identify it on the ANT network.
`ant_network`	INTEGER	ANT network this device communicates on, such as the public network or a Garmin-private network.
`source_type`	INTEGER	Transport this device connects over, such as ANT, ANT+, or Bluetooth Low Energy.
`product_name`	TEXT	Optional free form string to indicate the devices name or model.
`battery_level`	INTEGER	Remaining battery level as a percentage.

DeviceSettings

Stores user-configurable settings such as time zones, display modes, and backlight options.

Field	Type	Description
`file_number`	INTEGER	The file number.
`active_time_zone`	INTEGER	Index into time zone arrays.
`utc_offset`	INTEGER	Offset from system time. Required to convert timestamp from system time to UTC.
`time_offset`	TEXT	Timeoffset. units: s; Offset from system time.One value per configured time zone, indexed by active_time_zone.
`time_mode`	TEXT	Display mode for the time.One value per configured time zone, indexed by active_time_zone.
`time_zone_offset`	TEXT	Time zone offset. units: hr; scale: 4; timezone offset in 1/4 hour increments.One value per configured time zone, indexed by active_time_zone.
`backlight_mode`	INTEGER	Mode for backlight.
`activity_tracker_enabled`	INTEGER	Enabled state of the activity tracker functionality.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`clock_time`	TEXT	UTC timestamp used to set the device's clock and date, in ISO8601 format.
`pages_enabled`	TEXT	Bitfield to configure enabled screens for each supported loop.One bitfield value per supported display loop.
`move_alert_enabled`	INTEGER	Enabled state of the move alert.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`date_mode`	INTEGER	Display mode for the date.
`display_orientation`	INTEGER	Orientation the device's display is rotated to, such as portrait or landscape.
`mounting_side`	INTEGER	Which side of the body (or bike) the device is mounted on, used to orient the display correctly.
`default_page`	TEXT	Bitfield to indicate one page as default for each supported loop.One bitfield value per supported display loop.
`autosync_min_steps`	INTEGER	Auto sync minimum steps. Minimum steps before an autosync can occur.
`autosync_min_time`	INTEGER	Auto sync minimum time. Minimum minutes before an autosync can occur.
`lactate_threshold_autodetect_enabled`	INTEGER	Enable auto-detect setting for the lactate threshold feature.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`ble_auto_upload_enabled`	INTEGER	Automatically upload using BLE.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`auto_sync_frequency`	INTEGER	Helps to conserve battery by changing modes.
`auto_activity_detect`	INTEGER	Allows setting specific activities auto-activity detect enabled/disabled settings.
`number_of_screens`	INTEGER	Number of screens configured to display.
`smart_notification_display_orientation`	INTEGER	Orientation used specifically for displaying smart notifications, which may differ from the main display_orientation.
`tap_interface`	INTEGER	Mode controlling how tap gestures on the device are interpreted.
`tap_sensitivity`	INTEGER	Used to hold the tap threshold setting.

DiveAlarm

Defines alarms for depth, time, and other dive conditions.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of the alarm.
`depth`	REAL	Depth setting, in metres, for depth-type alarms.
`time`	INTEGER	Time setting (s) for time type alarms. Units: s.
`enabled`	INTEGER	Enablement flag.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`alarm_type`	INTEGER	Alarm type setting.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sound`	INTEGER	Tone and Vibe setting for the alarm.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`dive_types`	TEXT	Dive types the alarm will trigger on.One value per configured dive type.
`id`	INTEGER	Alarm ID.
`popup_enabled`	INTEGER	Show a visible pop-up for this alarm.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`trigger_on_descent`	INTEGER	Trigger the alarm on descent.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`trigger_on_ascent`	INTEGER	Trigger the alarm on ascent.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`repeating`	INTEGER	Repeat alarm each time threshold is crossed.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`speed`	REAL	Ascent/descent rate (mps) setting for speed type alarms. Units: mps.

DiveApneaAlarm

Defines alarms specific to apnea diving.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of the alarm.
`depth`	REAL	Depth setting, in metres, for depth-type alarms.
`time`	INTEGER	Time setting (s) for time type alarms. Units: s.
`enabled`	INTEGER	Enablement flag.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`alarm_type`	INTEGER	Alarm type setting.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sound`	INTEGER	Tone and Vibe setting for the alarm.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`dive_types`	TEXT	Dive types the alarm will trigger on.One value per configured dive type.
`id`	INTEGER	Alarm ID.
`popup_enabled`	INTEGER	Show a visible pop-up for this alarm.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`trigger_on_descent`	INTEGER	Trigger the alarm on descent.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`trigger_on_ascent`	INTEGER	Trigger the alarm on ascent.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`repeating`	INTEGER	Repeat alarm each time threshold is crossed?.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`speed`	REAL	Ascent/descent rate (mps) setting for speed type alarms. Units: mps.

DiveGas

Specifies gas mixture details for diving activities.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`helium_content`	INTEGER	Helium content of the gas mix, as a percentage.
`oxygen_content`	INTEGER	Oxygen content of the gas mix, as a percentage.
`status`	INTEGER	Status of this gas mix, such as enabled or disabled.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`mode`	INTEGER	Gas mode, such as open-circuit or closed-circuit rebreather.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

DiveSettings

DiveSettings contains configuration for dive activities including gas mixtures and safety parameters.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`dive_settings_name`	TEXT	User-assigned name for this dive settings profile.
`model`	INTEGER	Decompression model used for dive calculations.
`gf_low`	INTEGER	G flow.
`gf_high`	INTEGER	G flow high.
`water_type`	INTEGER	Type of water the dive computer is calibrated for, such as fresh or salt water.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`water_density`	REAL	Water density. Fresh water is usually 1000; salt water is usually 1025. Units: kg/m^3.
`po2_warn`	REAL	P O2 warning. Typically 1.40. Units: percent.
`po2_critical`	REAL	P O2 critical. Typically 1.60. Units: percent.
`po2_deco`	REAL	P O2 deco. Units: percent.
`safety_stop_enabled`	INTEGER	Whether safety stop guidance is enabled during ascent.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`bottom_depth`	REAL	Target bottom depth configured for this dive, in meters.
`bottom_time`	INTEGER	Target bottom time configured for this dive, in seconds.
`apnea_countdown_enabled`	INTEGER	Whether the apnea (breath-hold) countdown timer is enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`apnea_countdown_time`	INTEGER	Duration of the apnea countdown timer, in seconds.
`backlight_mode`	INTEGER	Mode controlling when the display backlight turns on during a dive.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`backlight_brightness`	INTEGER	Brightness level of the display backlight during a dive.
`backlight_timeout`	INTEGER	How long the display backlight stays on before turning off automatically, in seconds.
`repeat_dive_interval`	INTEGER	Repeat dive interval. Time between surfacing and ending the activity. Units: s.
`safety_stop_time`	INTEGER	Safety stop time. Time at safety stop (if enabled). Units: s.
`heart_rate_source_type`	INTEGER	Transport the heart rate source connects over, such as ANT or a local sensor.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`heart_rate_source`	INTEGER	Which paired heart rate source is used during dives.
`heart_rate_antplus_device_type`	INTEGER	Heart Rate ANT+ Device Type.
`heart_rate_local_device_type`	INTEGER	Locally-assigned device-type code of the heart rate source, when heart_rate_source_type is a local device.
`travel_gas`	INTEGER	Index of travel dive_gas message.
`ccr_low_setpoint_switch_mode`	INTEGER	If low PO2 should be switched to automatically.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`ccr_low_setpoint`	REAL	Target PO2 when using low setpoint. Units: percent.
`ccr_low_setpoint_depth`	REAL	Depth to switch to low setpoint in automatic mode. Units: m.
`ccr_high_setpoint_switch_mode`	INTEGER	If high PO2 should be switched to automatically.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`ccr_high_setpoint`	REAL	Target PO2 when using high setpoint. Units: percent.
`ccr_high_setpoint_depth`	REAL	Depth to switch to high setpoint in automatic mode. Units: m.
`gas_consumption_display`	INTEGER	Type of gas consumption rate to display. Some values are only valid if tank volume is known.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`up_key_enabled`	INTEGER	Indicates whether the up key is enabled during dives.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`dive_sounds`	INTEGER	Sounds and vibration enabled or disabled in-dive.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`last_stop_multiple`	REAL	Usually 1.0/1.5/2.0 representing 3/4.5/6m or 10/15/20ft.
`no_fly_time_mode`	INTEGER	Indicates which guidelines to use for no-fly surface interval.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

DiveSummary

Summary statistics for a single dive -- depth, surface interval, and CNS/gas-loading figures.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`reference_mesg`	INTEGER	Reference Message.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`reference_index`	INTEGER	Index of the specific referenced record (paired with reference_mesg, which identifies its message type).
`avg_depth`	REAL	Average deph. 0 if above water,. Units: m.
`max_depth`	REAL	Maximum depth. 0 if above water,. Units: m.
`surface_interval`	INTEGER	Surface interval. Time since end of last dive,. Units: s.
`start_cns`	INTEGER	CNS oxygen toxicity load at the start of the dive, as a percentage.
`end_cns`	INTEGER	CNS oxygen toxicity load at the end of the dive, as a percentage.
`start_n2`	INTEGER	Nitrogen loading at the start of the dive, as a percentage.
`end_n2`	INTEGER	Nitrogen loading at the end of the dive, as a percentage.
`o2_toxicity`	INTEGER	Oxygen toxicity load, in OTUs (oxygen toxicity units).
`dive_number`	INTEGER	Number identifying this dive within a multi-dive activity file, when applicable.
`bottom_time`	REAL	Time spent at depth during the dive, in seconds.
`avg_pressure_sac`	REAL	Average pressure. Average pressure-based surface air consumption. Units: bar/min.
`avg_volume_sac`	REAL	Average volume. Average volumetric surface air consumption. Units: L/min.
`avg_rmv`	REAL	Average RMV. Average respiratory minute volume.
`descent_time`	REAL	Descent time. Time to reach deepest level stop. Units: s.
`ascent_time`	REAL	Ascent time. Time after leaving bottom until reaching surface. Units: s.
`avg_ascent_rate`	REAL	Average ascent time. Average ascent rate, not including descents or stops. Units: m/s.
`avg_descent_rate`	REAL	Average descent rate. Average descent rate, not including ascents or stops. Units: m/s.
`max_ascent_rate`	REAL	Maximum ascent rate. Maximum ascent rate. Units: m/s.
`max_descent_rate`	REAL	Maximum descent rate. Maximum descent rate. Units: m/s.
`hang_time`	REAL	Hang time. Time spent neither ascending nor descending. Units: s.

Event

event_id: Represents significant occurrences during an activity such as start, stop, or alerts.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`event_id`	INTEGER	FIT event code identifying what triggered this record, such as a timer start/stop or a lap marker.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`event_type`	INTEGER	FIT event-type code describing how the event occurred, such as start, stop, or marker.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`data16`	INTEGER	Data 16.
`data`	INTEGER	Event-specific data value; its meaning depends on the event and event type.
`timer_trigger`	INTEGER	What triggered this timer-related event, such as a manual button press or auto-detected activity.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`course_point_index`	INTEGER	Index of the course point this event corresponds to, when triggered by reaching one.
`battery_level`	REAL	Raw battery voltage reading reported by this event, in volts -- distinct from the percentage-based battery_level fields on DeviceInfo/Record.
`virtual_partner_speed`	REAL	Virtial partner speed. Units: m/s.
`heart_rate_high_alert`	INTEGER	HR high alert.
`heart_rate_low_alert`	INTEGER	HR low alert.
`speed_high_alert`	REAL	Speed threshold for a high-speed alert, in meters per second.
`speed_low_alert`	REAL	Speed threshold for a low-speed alert, in meters per second.
`cad_high_alert`	INTEGER	Cadence high alert. Units: rpm.
`cad_low_alert`	INTEGER	Cadence low alert. Units: rpm.
`power_high_alert`	INTEGER	Power threshold for a high-power alert, in watts.
`power_low_alert`	INTEGER	Power high alert. Units: watts.
`time_duration_alert`	REAL	Time threshold for a duration-based alert, in seconds.
`distance_duration_alert`	REAL	Distance threshold for a distance-based alert, in meters.
`calorie_duration_alert`	INTEGER	Calorie threshold configured for a calorie-based duration alert, in kilocalories.
`fitness_equipment_state`	INTEGER	State of the connected fitness equipment, such as ready, in use, or paused.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sport_point`	INTEGER	Points scored, for sports that use a running point total (populated via the sport_point subfield alongside score/opponent_score).
`gear_change_data`	INTEGER	Gear change data,.
`rider_position`	INTEGER	Indicates the rider position value.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`comm_timeout`	INTEGER	Communication timeout that triggered this event, such as losing connection to a paired sensor.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`dive_alert`	INTEGER	Type of dive alert that triggered this event, such as an ascent-rate or decompression warning.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`auto_activity_detect_duration`	INTEGER	Auto activity detect duraiton. Units: min.
`radar_threat_alert`	INTEGER	Radar threat alert. The first byte is the radar_threat_level_max, the second byte is the radar_threat_count, third bytes is the average approach speed, and the 4th byte is the max approach speed.
`event_group`	INTEGER	Groups related events together, distinguishing concurrent event streams (such as separate segments within a multisport session) that share the same event_id and event_type.
`score`	INTEGER	Do not populate directly. Autogenerated by decoder for sport_point subfield components.
`opponent_score`	INTEGER	Do not populate directly. Autogenerated by decoder for sport_point subfield components.
`front_gear_number`	INTEGER	Fron gear number.
`front_gear`	INTEGER	Do not populate directly. Autogenerated by decoder for gear_change subfield components. Number of front teeth.
`rear_gear_number`	INTEGER	Read gear number.
`rear_gear`	INTEGER	Do not populate directly. Autogenerated by decoder for gear_change subfield components. Number of rear teeth.
`device_index`	INTEGER	Index identifying which connected device this data pertains to, matching a device_info record's own device_index.
`activity_type`	INTEGER	Activity Type associated with an auto_activity_detect event.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`start_timestamp`	TEXT	Timestamp of when the event started, in ISO8601 format.
`auto_activity_detect_start_timestamp`	TEXT	Timestamp of when auto-activity-detection started this event, in ISO8601 format.
`radar_threat_level_max`	INTEGER	Radar threat level maximum.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`radar_threat_count`	INTEGER	Do not populate directly. Autogenerated by decoder for threat_alert subfield components.
`radar_threat_avg_approach_speed`	REAL	Radar threat average approach speed. Units: m/s.
`radar_threat_max_approach_speed`	REAL	Do not populate directly. Autogenerated by decoder for radar_threat_alert subfield components. Units: m/s.

ExdDataConceptConfiguration

ExdDataConceptConfiguration.

Field	Type	Description
`file_number`	INTEGER	The file number.
`screen_index`	INTEGER	Index of the Connect IQ data-field screen this configuration entry belongs to.
`concept_field`	INTEGER	Connect IQ data-field concept identifier controlling what kind of data this screen entry displays.
`field_id`	INTEGER	Connect IQ data-field identifier assigned to this screen slot.
`concept_index`	INTEGER	Index of this concept within its data_page, when multiple concepts share the same page.
`data_page`	INTEGER	Data page number this concept configuration entry belongs to.
`concept_key`	INTEGER	Key identifying which specific concept (data source) is configured by this entry.
`scaling`	INTEGER	Scale factor applied to the displayed value.
`data_units`	INTEGER	Unit this data concept's displayed value is shown in (e.g. miles per hour, degrees Celsius, RPM, beats per minute).
`qualifier`	INTEGER	Qualifier identifying the variant of this data concept.
`descriptor`	INTEGER	Index of the descriptor string used to label this data concept.
`is_signed`	INTEGER	Whether the concept's value should be interpreted as signed rather than unsigned.Stored in SQLite as INTEGER: 0 = false, 1 = true.

ExdDataFieldConfiguration

ExdDataFieldConfiguration.

Field	Type	Description
`file_number`	INTEGER	The file number.
`screen_index`	INTEGER	Index of the Connect IQ data-field screen this configuration entry belongs to.
`concept_field`	INTEGER	Connect IQ data-field concept identifier controlling what kind of data this screen entry displays.
`field_id`	INTEGER	Connect IQ data-field identifier assigned to this screen slot.
`concept_count`	INTEGER	Number of concepts configured for this data field.
`display_type`	INTEGER	Display format used for this Connect IQ data field, such as numeric or text.
`title`	TEXT	Title text shown for this data field configuration.Normally a single-element array; the FIT profile permits more than one.

ExdScreenConfiguration

ExdScreenConfiguration.

Field	Type	Description
`file_number`	INTEGER	The file number.
`screen_index`	INTEGER	Index of the Connect IQ data-field screen this configuration entry belongs to.
`field_count`	INTEGER	Number of fields on the screen.
`layout`	INTEGER	Layout identifier for this data screen.
`screen_enabled`	INTEGER	Whether this Connect IQ data screen is enabled for display.Stored in SQLite as INTEGER: 0 = false, 1 = true.

ExerciseTitle

A user-defined exercise name, referenced by workout steps whose exercise_category/exercise_name fall in the user-defined range.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`exercise_category`	INTEGER	Raw FIT exercise-category code identifying the exercise family, such as Bench Press or Curl (see SetX's raw_category_garmin_key for its localized-name resolution).
`exercise_name`	INTEGER	Raw FIT exercise-name code identifying the specific exercise variant within its category (see SetX's raw_category_subtype_garmin_key for its localized-name resolution).
`workout_step_name`	TEXT	Custom display name for this user-defined exercise, referenced by workout steps whose exercise_category/exercise_name fall in the user-defined range.Normally a single-element array; the FIT profile permits more than one.

FieldCapabilities

Defines constraints on fields within messages, including counts and types.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`file`	INTEGER	FIT file type this capability entry applies to.
`mesg_number`	INTEGER	Message Number.
`field_number`	INTEGER	FIT field number (within mesg_number) this capability entry applies to.
`Count`	INTEGER	Number of instances of this field supported by the device.

FieldDescription

FieldDescription.

Field	Type	Description
`file_number`	INTEGER	The file number.
`developer_data_index`	INTEGER	Index identifying which DeveloperDataId source this field description belongs to.
`field_definition_number`	INTEGER	FIT field-definition number this developer field is assigned within its message.
`fit_base_type_id`	INTEGER	FIT base type (such as uint8 or sint16) this developer field's raw bytes should be interpreted as.
`field_name`	TEXT	Display name for this developer field.Normally a single-element array; the FIT profile permits more than one.
`array`	INTEGER	Number of elements if this developer field holds an array of values.
`components`	TEXT	Native fields this developer field expands into, if any.
`scale`	INTEGER	Scale factor applied when decoding this developer field.
`offset`	INTEGER	Value offset applied when decoding this developer field.
`units`	TEXT	Unit of measurement for this developer field's values.Normally a single-element array; the FIT profile permits more than one.
`bits`	TEXT	Bit-field layout of this developer field's value.
`accumulate`	TEXT	Whether values for this developer field accumulate across messages rather than overwrite the previous value.
`fit_base_unit_id`	INTEGER	FIT base unit this developer field's values are measured in, when applicable.
`native_mesg_number`	INTEGER	Native Message Number.
`native_field_number`	INTEGER	FIT field number of the native (built-in) field this developer field mirrors or extends, when applicable.

FileCapabilities

FileCapabilities defines limits and properties for files that the device can store.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`type`	INTEGER	The type.
`flags`	INTEGER	The flags.
`directory`	TEXT	The directory.
`max_count`	INTEGER	The maximum count.
`max_size`	INTEGER	Maximum size in bytes.

FileCreator

Is the record describing the device and software used to create the FIT file.

Field	Type	Description
`file_number`	INTEGER	The file number.
`software_version`	INTEGER	Software or firmware version installed on the device.
`hardware_version`	INTEGER	Hardware revision number of the device.

FileID

The record that identifies the file and the device that created it.

Field	Type	Description
`file_number`	INTEGER	—
`type`	INTEGER	FIT file type identifying what kind of file this is (activity, workout, course, settings, etc.) -- see the FileTypeLookup table for the full code-to-description mapping.
`manufacturer_id`	INTEGER	FIT manufacturer code identifying the device maker, such as Garmin or a third-party partner.
`product_id`	INTEGER	Manufacturer-specific product code identifying the device model; interpreted via garmin_product_id or favero_product_id when the manufacturer defines its own product-code table.
`favero_product_id`	INTEGER	Favero-specific product code identifying the device model, valid only when manufacturer_id is Favero Electronics.
`garmin_product_id`	INTEGER	Garmin-specific product code identifying the device model, valid only when manufacturer_id is Garmin.
`serial_number`	INTEGER	Serial number of the device, when available.
`time_created`	TEXT	Only set for files that can be created/erased, in ISO8601 format.
`number`	INTEGER	Only set for files that are not created/erased.
`product_name`	TEXT	Optional free form string to indicate the devices name or model.
`path`	TEXT	Filesystem path of the source .FIT file.
`imported_at`	TEXT	ISO8601 timestamp of when this file was imported.

Goal

Goal represents user-defined fitness goals including type, value, and recurrence.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`start_date`	TEXT	Date this goal becomes active, in ISO8601 format.
`end_date`	TEXT	Date this goal expires, in ISO8601 format.
`type`	INTEGER	Type of goal, such as distance, time, or calories.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`value`	INTEGER	Target value for the goal.
`repeat`	INTEGER	Number of times the goal repeats.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`target_value`	INTEGER	Target numeric value for this goal or workout step; its unit and meaning depend on the paired type field (such as goal_type or duration_type).
`recurrence`	INTEGER	How the goal recurs, such as daily, weekly, or monthly.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`recurrence_value`	INTEGER	How often the goal recurs, in units of the recurrence field (such as every N days or weeks).
`enabled`	INTEGER	Whether this goal is enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`source`	INTEGER	Source of the goal, such as auto-generated or user-created.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

GpsMetadata

GpsMetadata contains GPS-related data such as position, speed, and heading.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Whole second part of the timestamp, in ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`position_lat`	INTEGER	Latitude in semicircles.
`position_long`	INTEGER	Longitude in semicircles.
`enhanced_altitude`	REAL	Altitude at this point, in metres (extended-range GPS-metadata encoding).
`enhanced_speed`	REAL	Speed in meters per second, extended-range encoding.
`heading`	REAL	Heading in degrees.
`utc_timestamp`	TEXT	UTC time derived from the GPS data, in ISO8601 format, used to correlate UTC to system time if the timestamp of the message is in system time.
`velocity`	TEXT	units: m/s; scale: 100; velocity[0] is lon velocity. velocity[1] is lat velocity. velocity[2] is altitude velocity.Exactly three values: one per axis (longitude, latitude, altitude), in that order.

GyroscopeData

contains raw and calibrated gyroscope sensor readings.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Whole second part of the timestamp, in ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`sample_time_offset`	TEXT	Each time in the array describes the time, in milliseconds, at which the gyroscope sample with the corresponding index was taken. Limited to 30 samples per message; the samples may span across seconds. Array size must match the number of samples in gyro_x, gyro_y, and gyro_z.One value per sample, index-aligned with gyro_x/gyro_y/gyro_z.
`gyro_x`	TEXT	units: counts; These are the raw ADC reading. Maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`gyro_y`	TEXT	units: counts; These are the raw ADC reading. Maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`gyro_z`	TEXT	units: counts; These are the raw ADC reading. Maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`calibrated_gyro_x`	TEXT	units: deg/s; Calibrated gyro reading.One value per sample, index-aligned with sample_time_offset.
`calibrated_gyro_y`	TEXT	units: deg/s; Calibrated gyro reading.One value per sample, index-aligned with sample_time_offset.
`calibrated_gyro_z`	TEXT	units: deg/s; Calibrated gyro reading.One value per sample, index-aligned with sample_time_offset.

Hr

- heart rate.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`fractional_timestamp`	REAL	Fractional-second part of the timestamp, in seconds.
`time256`	REAL	Time in seconds, encoded at 1/256-second resolution.
`filtered_bpm`	TEXT	Filtered heart rate in beats per minute.One value per detected heart-rate event, index-aligned with event_timestamp -- the FIT SDK requires both arrays to have the same number of values in a given message.
`event_timestamp`	TEXT	Time offset from this message's anchor timestamp at which each heart-rate event was detected. units: s; scale: 1024.One value per detected heart-rate event, index-aligned with filtered_bpm.
`event_timestamp12`	TEXT	Alternate, more compact byte-packed encoding of per-event timestamps, used instead of event_timestamp when the device reports events this way. units: s; scale: 1024.One value per encoded byte of this compact per-event timestamp series; not necessarily the same element count as event_timestamp/filtered_bpm.

HrmProfile

Stores configuration for heart rate monitor sensors.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`enabled`	INTEGER	Whether this heart rate monitor profile is enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`hrm_ant_id`	INTEGER	ANT device ID of the heart rate monitor paired with this profile.
`log_hrv`	INTEGER	Whether heart rate variability (HRV) data is logged for this profile.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`hrm_ant_id_trans_type`	INTEGER	ANT transmission type of the heart rate monitor identified by hrm_ant_id.

Hrv

Heart-rate-variability samples -- time between successive heartbeats.

Field	Type	Description
`file_number`	INTEGER	The file number.
`time`	TEXT	units: s; scale: 1000; Time between beats.One value per successive heartbeat interval, in chronological order.

HrvStatusSummary

Rolling summary of heart-rate-variability trends over recent nights, plus an overall HRV status classification (e.g. balanced, low).

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`weekly_average`	REAL	units: ms; scale: 128; 7 day RMSSD average over sleep.
`last_night_average`	REAL	units: ms; scale: 128; Last night RMSSD average over sleep.
`last_night5_min_high`	REAL	units: ms; scale: 128; 5 minute high RMSSD value over sleep.
`baseline_low_upper`	REAL	units: ms; scale: 128; 3 week baseline, upper boundary of low HRV status.
`baseline_balanced_lower`	REAL	units: ms; scale: 128; 3 week baseline, lower boundary of balanced HRV status.
`baseline_balanced_upper`	REAL	units: ms; scale: 128; 3 week baseline, upper boundary of balanced HRV status.
`status`	INTEGER	Overall HRV status classification.

HrvValue

A single rolling RMSSD (heart-rate-variability) sample.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`value`	REAL	5-minute rolling RMSSD (Root Mean Square of Successive Differences between heartbeat intervals) -- a standard heart-rate-variability metric. units: ms; scale: 128.

HrZone

HrZone defines heart rate training zones.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Message index.
`high_bpm`	INTEGER	—. Units: bpm.
`heart_rate_zone_name`	TEXT	User-assigned name for this heart rate zone.

HsaAccelerometerData

Hsa_accelerometer_data: Raw accelerometer data used for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`sampling_interval`	INTEGER	Sampling Interval in Milliseconds.
`accel_x`	TEXT	units: mG; scale: 1.024; X-Axis Measurement.One value per sample, spaced sampling_interval milliseconds apart, index-aligned with accel_y/accel_z.
`accel_y`	TEXT	units: mG; scale: 1.024; Y-Axis Measurement.One value per sample, spaced sampling_interval milliseconds apart, index-aligned with accel_x/accel_z.
`accel_z`	TEXT	units: mG; scale: 1.024; Z-Axis Measurement.One value per sample, spaced sampling_interval milliseconds apart, index-aligned with accel_x/accel_y.
`timestamp32k`	TEXT	32 kHz timestamp.

HsaBodyBatteryData

Hsa_body_battery_data: Body battery data used for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`processing_interval`	INTEGER	Processing interval length in seconds.
`level`	TEXT	units: percent; Body battery level: [0,100] Blank: -16.One value per sample, spaced processing_interval seconds apart, index-aligned with charged/uncharged.
`charged`	TEXT	Body battery charged value.One value per sample, spaced processing_interval seconds apart, index-aligned with level/uncharged.
`uncharged`	TEXT	Body battery uncharged value.One value per sample, spaced processing_interval seconds apart, index-aligned with level/charged.

HsaConfigurationData

Hsa_configuration_data: Configuration data for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`data`	TEXT	Encoded configuration data. Health SDK use only.One byte per element; length given by data_size.
`data_size`	INTEGER	size in bytes of data field.

HsaEvent

Hsa_event: HSA events.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`event_id`	INTEGER	Event ID. Health SDK use only.

HsaGyroscopeData

Hsa_gyroscope_data:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`sampling_interval`	INTEGER	Sampling Interval in 32 kHz timescale. Units: 1/32768 s.
`gyro_x`	TEXT	units: deg/s; scale: 28.57143; X-Axis Measurement.One value per sample, spaced sampling_interval apart, index-aligned with gyro_y/gyro_z.
`gyro_y`	TEXT	units: deg/s; scale: 28.57143; Y-Axis Measurement.One value per sample, spaced sampling_interval apart, index-aligned with gyro_x/gyro_z.
`gyro_z`	TEXT	units: deg/s; scale: 28.57143; Z-Axis Measurement.One value per sample, spaced sampling_interval apart, index-aligned with gyro_x/gyro_y.
`timestamp32k`	TEXT	32 kHz timestamp.

HsaHeartRateData

Hsa_heart_rate_data: User's current heart rate data used for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`processing_interval`	INTEGER	Processing interval length in seconds.
`status`	INTEGER	Of measurements in buffer - 0 indicates SEARCHING 1 indicates LOCKED.
`heart_rate`	TEXT	units: bpm; scale: 1; Beats / min. Blank: 0.One value per sample, spaced processing_interval seconds apart.

HsaRespirationData

Hsa_respiration_data: User's current respiration data used for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`processing_interval`	INTEGER	Processing interval length in seconds.
`respiration_rate`	TEXT	Respiration rate, in breaths per minute (valid range 1-100).One value per sample, spaced processing_interval seconds apart. Sentinel values outside the valid range: 255 = invalid, 254 = excess motion, 253 = off-wrist, 252 = not available, 2.4 = blank. units: breaths/min; scale: 100.

HsaSpo2Data

Hsa_spo2_data: User's current SpO2 data used for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`processing_interval`	INTEGER	Processing interval length in seconds.
`reading_spo2`	TEXT	units: percent; SpO2 Reading: [70,100] Blank: 240.One value per sample, spaced processing_interval seconds apart, index-aligned with confidence.
`confidence`	TEXT	SpO2 confidence: [0,254].One value per sample, spaced processing_interval seconds apart, index-aligned with reading_spo2.

HsaStepData

Hsa_step_data: User's current daily step data used for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`processing_interval`	INTEGER	Processing interval length in seconds.
`steps`	TEXT	units: steps; scale: 1; Total step sum.One value per sample, spaced processing_interval seconds apart.

HsaStressData

Hsa_stress_data: User's current stress data used for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`processing_interval`	INTEGER	Processing interval length in seconds.
`StressLevel`	TEXT	units: s; scale: 1; Stress Level: [0,100] Off wrist: -1 Excess motion: -2 Not enough data: -3 Recovering from exercise: -4 Unidentified: -5 Blank: -16.One value per sample, spaced processing_interval seconds apart.

HsaWristTemperatureData

Hsa_wrist_temperature_data: Wrist temperature data used for HSA custom data logging.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`processing_interval`	INTEGER	Processing interval length in seconds.
`value`	TEXT	units: degC; scale: 1000; Wrist temperature reading.One value per sample, spaced processing_interval seconds apart.

Jump

A single detected jump (e.g. ski or snowboard), including its distance, height, rotation count, airtime, and a composite score.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`distance`	REAL	Horizontal distance covered by the jump, in meters.
`height`	REAL	height of the jump in meters.
`rotations`	INTEGER	Number of rotations completed during the jump.
`hang_time`	REAL	Time spent airborne during the jump, in seconds.
`score`	REAL	A score for a jump calculated based on hang time, rotations, and distance.
`position_lat`	INTEGER	Latitude in semicircles.
`position_long`	INTEGER	Longitude in semicircles.
`speed`	REAL	speed at takeoff, in meters per second.
`enhanced_speed`	REAL	speed in meters per second, extended-range encoding.

Lap

contains data for a single lap within a session.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`timestamp`	TEXT	In ISO8601 format.
`event_id`	INTEGER	FIT event code identifying what triggered this record, such as a timer start/stop or a lap marker.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`event_type`	INTEGER	FIT event-type code describing how the event occurred, such as start, stop, or marker.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`start_time`	TEXT	Start time of the lap, in ISO8601 format.
`start_position_lat`	INTEGER	Latitude of the start position, in semicircles.
`start_position_long`	INTEGER	Longitude of the start position, in semicircles.
`end_position_lat`	INTEGER	Latitude of the end position, in semicircles.
`end_position_long`	INTEGER	Longitude of the end position, in semicircles.
`total_elapsed_time`	REAL	Time (includes pauses). Units: s.
`total_timer_time`	REAL	Timer Time (excludes pauses). Units: s.
`total_distance`	REAL	Total distance in meters.
`total_cycles`	INTEGER	Total cycles, such as pedal revolutions or steps.
`total_strides`	INTEGER	Total number of strides.
`total_strokes`	INTEGER	Total number of strokes.
`total_calories`	INTEGER	Total calories burned, in kilocalories.
`total_fat_calories`	INTEGER	Total calories burned from fat, in kilocalories.
`avg_speed`	REAL	Average speed in meters per second.
`max_speed`	REAL	Maximum speed in meters per second.
`avg_heart_rate`	INTEGER	Average heart rate in beats per minute.
`max_heart_rate`	INTEGER	Maximum heart rate in beats per minute.
`avg_cadence`	INTEGER	Average cadence, in revolutions per minute -- computed by the recording device as total_cycles / total_timer_time, or total_cycles / total_elapsed_time, depending on a device setting not otherwise captured in this data.
`avg_running_cadence`	INTEGER	Average running cadence in strides per minute.
`max_cadence`	INTEGER	Maximum cadence in revolutions per minute.
`max_running_cadence`	INTEGER	Maximum running cadence in strides per minute.
`avg_power`	INTEGER	Average power, in watts -- computed by the recording device from its own internal power total, divided by total_timer_time or total_elapsed_time depending on a device setting; neither the power total nor the setting is otherwise captured in this data.
`max_power`	INTEGER	Maximum power in watts.
`total_ascent`	INTEGER	Total ascent in meters.
`total_descent`	INTEGER	Total descent in meters.
`intensity`	INTEGER	Intensity classification of the lap, such as active or rest.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`lap_trigger`	INTEGER	What triggered the end of this lap, such as a manual button press or auto-lap distance.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`event_group`	INTEGER	Groups related events together, distinguishing concurrent event streams (such as separate segments within a multisport session) that share the same event_id and event_type.
`number_lengths`	INTEGER	# of lengths of swim pool.
`normalized_power`	INTEGER	Normalized power in watts.
`left_right_balance`	INTEGER	Left/right power balance as a percentage, encoded per the FIT left_right_balance_100 type (high bit flags the measurement source).
`first_length_index`	INTEGER	Index of the first length (in the parent Session's swim lengths) belonging to this lap.
`avg_stroke_distance`	REAL	Average distance covered per stroke, in meters.
`swim_stroke`	INTEGER	Swimming stroke type used during this lap.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`number_active_lengths`	INTEGER	# of active lengths of swim pool.
`total_work`	INTEGER	Total work performed, in joules.
`avg_altitude`	REAL	Average altitude during this lap, in metres.
`max_altitude`	REAL	Maximum altitude reached during this lap, in metres.
`gps_accuracy`	INTEGER	Estimated GPS position accuracy, in meters.
`avg_grade`	REAL	Average grade (slope) as a percentage.
`avg_pos_grade`	REAL	Average ascending grade, as a percentage.
`avg_neg_grade`	REAL	Average descending grade, as a percentage.
`max_pos_grade`	REAL	Steepest ascending grade, as a percentage.
`max_neg_grade`	REAL	Steepest descending grade, as a percentage.
`avg_temperature`	INTEGER	Average temperature in degrees Celsius.
`max_temperature`	INTEGER	Maximum temperature in degrees Celsius.
`total_moving_time`	REAL	Total time spent moving, in seconds.
`avg_pos_vertical_speed`	REAL	Average ascending vertical speed, in meters per second.
`avg_neg_vertical_speed`	REAL	Average descending vertical speed, in meters per second.
`max_pos_vertical_speed`	REAL	Maximum ascending vertical speed, in meters per second.
`max_neg_vertical_speed`	REAL	Maximum descending vertical speed, in meters per second.
`time_in_heart_rate_zone`	TEXT	Total time spent in each heart-rate training zone during this lap. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_speed_zone`	TEXT	Total time spent in each speed training zone during this lap. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_cadence_zone`	TEXT	Total time spent in each cadence training zone during this lap. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_power_zone`	TEXT	Total time spent in each power training zone during this lap. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`repetition_number`	INTEGER	Ordinal position of this lap within a repeated/looped sequence of laps.
`min_altitude`	REAL	Minimum altitude reached during this lap, in metres.
`min_heart_rate`	INTEGER	Minimum heart rate in beats per minute.
`workout_step_index`	INTEGER	Index of the workout_step (in the parent Workout) that produced this record, when generated by a structured workout.
`opponent_score`	INTEGER	Opponent's score in games or sports with an adversarial scoring system, such as squash or racquetball.
`stroke_count`	TEXT	Number of times each swimming stroke type was used.One value per stroke_type enum value.
`zone_count`	TEXT	Count recorded for each zone.One value per zone.
`avg_vertical_oscillation`	REAL	Average vertical oscillation in millimeters.
`avg_stance_time_percent`	REAL	Average ground contact time as a percentage of the stride cycle.
`avg_stance_time`	REAL	Average ground contact time per step, in milliseconds.
`avg_fractional_cadence`	REAL	Fractional part of the avg_cadence. Units: rpm.
`max_fractional_cadence`	REAL	Fractional part of the max_cadence. Units: rpm.
`total_fractional_cycles`	REAL	Fractional part of the total_cycles. Units: cycles.
`player_score`	INTEGER	This user's own score in games or sports with a scoring system, such as squash or racquetball.
`avg_total_hemoglobin_conc`	TEXT	units: g/dL; scale: 100; Avg saturated and unsaturated hemoglobin.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`min_total_hemoglobin_conc`	TEXT	units: g/dL; scale: 100; Min saturated and unsaturated hemoglobin.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`max_total_hemoglobin_conc`	TEXT	units: g/dL; scale: 100; Max saturated and unsaturated hemoglobin.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`avg_saturated_hemoglobin_percent`	TEXT	units: %; scale: 10; Avg percentage of hemoglobin saturated with oxygen.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`min_saturated_hemoglobin_percent`	TEXT	units: %; scale: 10; Min percentage of hemoglobin saturated with oxygen.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`max_saturated_hemoglobin_percent`	TEXT	units: %; scale: 10; Max percentage of hemoglobin saturated with oxygen.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`avg_left_torque_effectiveness`	REAL	Average left torque effectiveness, as a percentage.
`avg_right_torque_effectiveness`	REAL	Average right torque effectiveness, as a percentage.
`avg_left_pedal_smoothness`	REAL	Average left pedal smoothness, as a percentage.
`avg_right_pedal_smoothness`	REAL	Average right pedal smoothness, as a percentage.
`avg_combined_pedal_smoothness`	REAL	Average combined pedal smoothness, as a percentage.
`time_standing`	REAL	Total time spent in the standing position. Units: s.
`stand_count`	INTEGER	Number of transitions to the standing state.
`avg_left_pco`	INTEGER	Average left platform center offset. Units: mm.
`avg_right_pco`	INTEGER	Average right platform center offset. Units: mm.
`avg_left_power_phase`	TEXT	Average left-leg pedal-stroke power-phase angles, in degrees of crank rotation -- the portion of each pedal stroke where meaningful force is applied. Each of the 4 array elements is a different measurement of that phase (start angle, end angle, arc length, center), per power_phase_type.One value per power_phase_type enum value.
`avg_left_power_phase_peak`	TEXT	As avg_left_power_phase, but for the power phase during this lap's single hardest effort rather than averaged across the whole lap.One value per power_phase_type enum value.
`avg_right_power_phase`	TEXT	As avg_left_power_phase, for the right leg.One value per power_phase_type enum value.
`avg_right_power_phase_peak`	TEXT	As avg_left_power_phase_peak, for the right leg.One value per power_phase_type enum value.
`avg_power_position`	TEXT	Average power, in watts, broken out by rider position (seated, standing, or transitioning between them) -- one value per rider_position_type.One value per rider_position_type enum value.
`max_power_position`	TEXT	As avg_power_position, but the maximum power reached rather than the average.One value per rider_position_type enum value.
`avg_cadence_position`	TEXT	Average cadence, in revolutions per minute, broken out by rider position (seated, standing, or transitioning between them).One value per rider_position_type enum value.
`max_cadence_position`	TEXT	As avg_cadence_position, but the maximum cadence reached rather than the average.One value per rider_position_type enum value.
`enhanced_avg_speed`	REAL	Average speed in meters per second, extended-range encoding.
`enhanced_max_speed`	REAL	Maximum speed in meters per second, extended-range encoding.
`enhanced_avg_altitude`	REAL	Average altitude during this lap, in metres (extended-range counterpart to avg_altitude).
`enhanced_min_altitude`	REAL	Minimum altitude reached during this lap, in metres (extended-range counterpart to min_altitude).
`enhanced_max_altitude`	REAL	Maximum altitude reached during this lap, in metres (extended-range counterpart to max_altitude).
`avg_lev_motor_power`	INTEGER	Lev average motor power during lap. Units: watts.
`max_lev_motor_power`	INTEGER	Lev maximum motor power during lap. Units: watts.
`lev_battery_consumption`	REAL	Lev battery consumption during lap. Units: percent.
`avg_vertical_ratio`	REAL	Average vertical ratio, as a percentage.
`avg_stance_time_balance`	REAL	Average left/right balance of ground contact time, as a percentage.
`avg_step_length`	REAL	Average step length in millimeters.
`avg_vam`	REAL	Average ascent speed (VAM) in meters per second.
`avg_depth`	REAL	0 if above water. Units: m.
`max_depth`	REAL	0 if above water. Units: m.
`min_temperature`	INTEGER	Minimum temperature in degrees Celsius.
`enhanced_avg_respiration_rate`	REAL	Average respiration rate in breaths per minute.
`enhanced_max_respiration_rate`	REAL	Maximum respiration rate in breaths per minute.
`avg_respiration_rate`	INTEGER	Average respiration rate during this period, in breaths per minute; superseded by the wider-range enhanced_avg_respiration_rate where present.
`max_respiration_rate`	INTEGER	Maximum respiration rate during this period, in breaths per minute; superseded by the wider-range enhanced_max_respiration_rate where present.
`total_grit`	REAL	The grit score estimates how challenging a route could be for a cyclist in terms of time spent going over sharp turns or large grade slopes. Units: kGrit.
`total_flow`	REAL	The flow score estimates how long distance wise a cyclist deaccelerates over intervals where deacceleration is unnecessary such as smooth turns or small grade angle intervals. Units: Flow.
`jump_count`	INTEGER	Number of jumps detected during this period, such as skiing or snowboarding jumps.
`avg_grit`	REAL	The grit score estimates how challenging a route could be for a cyclist in terms of time spent going over sharp turns or large grade slopes. Units: kGrit.
`avg_flow`	REAL	The flow score estimates how long distance wise a cyclist deaccelerates over intervals where deacceleration is unnecessary such as smooth turns or small grade angle intervals. Units: Flow.
`total_fractional_ascent`	REAL	Fractional part of total_ascent. Units: m.
`total_fractional_descent`	REAL	Fractional part of total_descent. Units: m.
`avg_core_temperature`	REAL	Average core body temperature in degrees Celsius.
`min_core_temperature`	REAL	Minimum core body temperature in degrees Celsius.
`max_core_temperature`	REAL	Maximum core body temperature in degrees Celsius.

Length

contains data for a single length in swimming activities.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`timestamp`	TEXT	In ISO8601 format.
`event_id`	INTEGER	FIT event code identifying what triggered this record, such as a timer start/stop or a lap marker.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`event_type`	INTEGER	FIT event-type code describing how the event occurred, such as start, stop, or marker.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`start_time`	TEXT	Start time of the length, in ISO8601 format.
`total_elapsed_time`	REAL	Total elapsed time, including pauses, in seconds.
`total_timer_time`	REAL	Total timer time, excluding pauses, in seconds.
`total_strokes`	INTEGER	Total number of strokes.
`avg_speed`	REAL	Average speed in meters per second.
`swim_stroke`	INTEGER	Swimming stroke type used.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`avg_swimming_cadence`	INTEGER	Average swimming cadence in strokes per minute.
`event_group`	INTEGER	Groups related events together, distinguishing concurrent event streams (such as separate segments within a multisport session) that share the same event_id and event_type.
`total_calories`	INTEGER	Total calories burned, in kilocalories.
`length_type`	INTEGER	Classification of this length, such as active or idle (a rest length between active swimming).The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`player_score`	INTEGER	This user's own score in games or sports with a scoring system, such as squash or racquetball.
`opponent_score`	INTEGER	Opponent's score in games or sports with an adversarial scoring system, such as squash or racquetball.
`stroke_count`	TEXT	Number of times each swimming stroke type was used.One value per stroke_type enum value.
`zone_count`	TEXT	Count recorded for each zone.One value per zone.
`enhanced_avg_respiration_rate`	REAL	Average respiration rate in breaths per minute.
`enhanced_max_respiration_rate`	REAL	Maximum respiration rate in breaths per minute.
`avg_respiration_rate`	INTEGER	Average respiration rate during this period, in breaths per minute; superseded by the wider-range enhanced_avg_respiration_rate where present.
`max_respiration_rate`	INTEGER	Maximum respiration rate during this period, in breaths per minute; superseded by the wider-range enhanced_max_respiration_rate where present.

MagnetometerData

contains raw and calibrated magnetometer sensor readings.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Whole second part of the timestamp, in ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`sample_time_offset`	TEXT	Each time in the array describes the time, in milliseconds, at which the magnetometer sample with the corresponding index was taken. Limited to 30 samples per message; the samples may span across seconds. Array size must match the number of samples in mag_x, mag_y, and mag_z.One value per sample, index-aligned with mag_x/mag_y/mag_z.
`mag_x`	TEXT	units: counts; These are the raw ADC reading. Maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`mag_y`	TEXT	units: counts; These are the raw ADC reading. Maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`mag_z`	TEXT	units: counts; These are the raw ADC reading. Maximum number of samples is 30 in each message. The samples may span across seconds. A conversion will need to be done on this data once read.One value per sample, index-aligned with sample_time_offset.
`calibrated_mag_x`	TEXT	units: G; Calibrated Magnetometer reading.One value per sample, index-aligned with sample_time_offset.
`calibrated_mag_y`	TEXT	units: G; Calibrated Magnetometer reading.One value per sample, index-aligned with sample_time_offset.
`calibrated_mag_z`	TEXT	units: G; Calibrated Magnetometer reading.One value per sample, index-aligned with sample_time_offset.

MaxMetData

Max_met_data:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`update_time`	TEXT	Time maxMET and vo2 were calculated, in ISO8601 format.
`vo2_max`	REAL	Estimated VO2 max, in milliliters per kilogram per minute.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.
`max_met_category`	INTEGER	Category of activity used when estimating max MET/VO2max, such as running or cycling.
`calibrated_data`	INTEGER	Indicates if calibrated data was used in the calculation.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`heart_rate_source`	INTEGER	Indicates if the estimate was obtained using a chest strap or wrist heart rate.
`speed_source`	INTEGER	Indidcates if the estimate was obtained using onboard GPS or connected GPS.

MemoGlob

Memo_glob:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`part_index`	INTEGER	Sequence number of memo blocks.
`memo`	TEXT	Deprecated. Use data field.One byte per element of this deprecated raw byte array.
`mesg_number`	INTEGER	Message Number of the parent message.
`parent_index`	INTEGER	Index of mesg that this glob is associated with.
`field_number`	INTEGER	Field within the parent that this glob is associated with.
`data`	TEXT	Block of utf8 bytes. Note, mutltibyte characters may be split across adjoining memo_glob messages.One byte per element of this UTF-8 byte block.

MesgCapabilities

Specifies constraints on message types and counts within a FIT file.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`file`	INTEGER	The file number.
`mesg_number`	INTEGER	The message number.
`count_type`	INTEGER	The count type.
`Count`	INTEGER	Number of instances of this message supported by the device.
`number_per_file`	INTEGER	Num per file.
`max_per_file`	INTEGER	Maximum number of instances of this message type supported per file.
`max_per_file_type`	INTEGER	How max_per_file's limit is scoped, such as per file, per file and sport, or per file and sport and sub-sport.

MetZone

Defines metabolic equivalent zones for estimating energy expenditure.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`high_bpm`	INTEGER	Upper boundary of this MET zone, in beats per minute.
`calories`	REAL	Calorie-burn threshold for this MET zone, in kilocalories.
`fat_calories`	REAL	Rate of calories burned from fat metabolism while in this MET zone. Units: kcal / min.

Monitoring

A periodic wellness/activity-monitoring log entry -- accumulated calories, distance, cycles, and steps for one logging interval.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format. Must align to logging interval, for example, time must be 00:00:00 for daily log.
`device_index`	INTEGER	Associates this data to device_info message. Not required for file with single device (sensor).
`calories`	INTEGER	Accumulated total calories. Maintained by MonitoringReader for each activity_type. See SDK documentation.
`distance`	REAL	Accumulated distance. Maintained by MonitoringReader for each activity_type. See SDK documentation. Units: m.
`cycles`	REAL	Accumulated cycles. Maintained by MonitoringReader for each activity_type. See SDK documentation.
`steps`	INTEGER	Total step count during the logging interval.
`strokes`	REAL	Accumulated stroke count during the logging interval.
`active_time`	REAL	Active time in seconds.
`activity_type`	INTEGER	FIT activity-type code classifying the kind of activity this sample represents, such as walking, running, or sleeping.
`activity_subtype`	INTEGER	FIT activity-subtype code providing a more specific classification within activity_type.
`activity_level`	INTEGER	Intensity level of the tracked activity, such as low, medium, or high.
`distance16`	INTEGER	Low 16 bits of the cumulative distance; combine with the matching distance field to reconstruct the full value.
`cycles16`	INTEGER	Low 16 bits of the cumulative cycle count; combine with the matching cycles field to reconstruct the full value.
`active_time16`	INTEGER	Low 16 bits of the active-time counter; combine with the matching active-time field to reconstruct the full value.
`local_timestamp`	TEXT	In ISO8601 format. Must align to logging interval, for example, time must be 00:00:00 for daily log.
`temperature`	REAL	Avg temperature during the logging interval ended at timestamp. Units: C.
`temperature_min`	REAL	Min temperature during the logging interval ended at timestamp.
`temperature_max`	REAL	Max temperature during the logging interval ended at timestamp. Units: C.
`activity_time`	TEXT	units: minutes; Indexed using minute_activity_level enum.One value per minute_activity_level enum value.
`active_calories`	INTEGER	Active calories burned, in kilocalories.
`current_activity_type_intensity`	INTEGER	Indicates single type / intensity for duration since last monitoring message.
`timestamp_min8`	TEXT	Low bits of the timestamp, in minutes; combine with the matching timestamp field to reconstruct the full value.
`timestamp16`	TEXT	Low bits of the timestamp; combine with the matching timestamp field to reconstruct the full value.
`heart_rate`	INTEGER	Heart rate in beats per minute.
`intensity`	REAL	Activity intensity level during the logging interval.
`duration_min`	INTEGER	duration in minutes.
`duration`	INTEGER	Length of the logging interval, in seconds.
`ascent`	REAL	Accumulated ascent in meters during the logging interval.
`descent`	REAL	Accumulated descent in meters during the logging interval.
`moderate_activity_minutes`	INTEGER	Minutes spent in moderate-intensity activity.
`vigorous_activity_minutes`	INTEGER	Minutes spent in vigorous-intensity activity.
`pushes`	INTEGER	Wheelchair pushes recorded in this monitoring period.

MonitoringHrData

Monitoring_hr_data:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format. Must align to logging interval, for example, time must be 00:00:00 for daily log.
`resting_heart_rate`	INTEGER	7-day rolling average. Units: bpm.
`current_day_resting_heart_rate`	INTEGER	RHR for today only. (Feeds into 7-day average). Units: bpm.

MonitoringInfo

Monitoring_info:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`local_timestamp`	TEXT	Timestamp epoch expressed in local time, in ISO8601 format, used to convert activity timestamps to local time if the device does not support time zone and daylight savings time correction.
`activity_type`	TEXT	FIT activity-type codes this file tracks calorie/distance conversion factors for; indexes cycles_to_distance and cycles_to_calories.One value per tracked activity type; its own array order is the index cycles_to_distance and cycles_to_calories are aligned to.
`cycles_to_distance`	TEXT	units: m/cycle; scale: 5000; Indexed by activity_type.One value per element of activity_type, index-aligned with it.
`cycles_to_calories`	TEXT	units: kcal/cycle; scale: 5000; Indexed by activity_type.One value per element of activity_type, index-aligned with it.
`resting_metabolic_rate`	INTEGER	Estimated calories burned per day at rest (basal metabolic rate). Units: kcal / day.

NapEvent

Nap Event record.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`timestamp`	TEXT	In ISO8601 format.
`start_time`	TEXT	Start of the nap period, in ISO8601 format.
`start_timezone_offset`	INTEGER	Timezone offset at start of the nap period. Units: minutes.
`end_time`	TEXT	End of the nap period, in ISO8601 format.
`end_timezone_offset`	INTEGER	Timezone offset at end of the nap period. Units: minutes.
`feedback`	INTEGER	The device's assessment of this nap's timing and duration relative to sleep need and jetlag state (e.g. ideal timing, late timing, or a duration mismatch).
`is_deleted`	INTEGER	Whether this nap event has been deleted.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`source`	INTEGER	How this nap was recorded -- detected automatically by the device, entered manually on the device, or entered manually via Garmin Connect.
`update_timestamp`	TEXT	timestamp this record was last updated, in ISO8601 format.

NmeaSentence

Stores raw NMEA sentences from GPS devices.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Fractional part of timestamp, added to timestamp. Units: ms.
`sentence`	TEXT	NMEA sentence.

ObdiiData

contains vehicle diagnostic data captured during an activity.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Time the message was output, in ISO8601 format.
`timestamp_ms`	INTEGER	Fractional part of timestamp, added to timestamp. Units: ms.
`time_offset`	TEXT	units: ms; Offset of PID reading [i] from start_timestamp+start_timestamp_ms. Readings may span across seconds.One value per PID reading, index-aligned with raw_data.
`pid`	INTEGER	Parameter ID.
`raw_data`	TEXT	Raw parameter data.One value per PID reading, index-aligned with time_offset/system_time.
`pid_data_size`	TEXT	Optional, data size of PID[i]. If not specified refer to SAE J1979.One value per PID reading, index-aligned with raw_data.
`system_time`	TEXT	System time associated with sample expressed in ms, can be used instead of time_offset. There will be a system_time value for each raw_data element. For multibyte pids the system_time is repeated.One value per raw_data element, index-aligned with it.
`start_timestamp`	TEXT	timestamp of first sample recorded in the message, in ISO8601 format. Used with time_offset to generate time of each sample.
`start_timestamp_ms`	INTEGER	Fractional part of start_timestamp. Units: ms.

OhrSettings

Configures optical heart rate sensor settings.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`enabled`	INTEGER	Whether the optical heart rate sensor is enabled.

OneDSensorCalibration

Stores calibration data for 1D sensors such as barometers.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Whole second part of the timestamp, in ISO8601 format.
`sensor_type`	INTEGER	Indicates which sensor the calibration is for.
`calibration_factor`	INTEGER	Calibration factor used to convert from raw ADC value to degrees, g, etc.
`baro_cal_factor`	INTEGER	Barometer calibration factor. Units: Pa.
`calibration_divisor`	INTEGER	Calibration factor divisor. Units: counts.
`level_shift`	INTEGER	Level shift value used to shift the ADC value back into range.
`offset_cal`	INTEGER	Internal Calibration factor.

PowerZone

Defines power training zones.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`high_value`	INTEGER	Upper boundary of this power zone, in watts.
`Name`	TEXT	User-assigned name for this power zone.

RawBbi

Raw_bbi: Raw Beat-to-Beat Interval values.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`data`	TEXT	1 bit for gap indicator, 1 bit for quality indicator, and 14 bits for Beat-to-Beat interval values in whole-integer millisecond resolution.One value per beat interval, index-aligned with time/quality/gap.
`time`	TEXT	units: ms; Array of millisecond times between beats.One value per beat interval, index-aligned with data/quality/gap.
`quality`	TEXT	1 = high confidence. 0 = low confidence. N/A when gap = 1.One value per beat interval, index-aligned with data/time/gap.
`gap`	TEXT	1 = gap (time represents ms gap length). 0 = BBI data.One value per beat interval, index-aligned with data/time/quality.

Record

Is the primary data message containing timestamped sensor readings such as position, speed, and heart rate.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`position_lat`	INTEGER	Latitude in semicircles.
`position_long`	INTEGER	Longitude in semicircles.
`altitude`	REAL	Altitude at this point, in metres.
`heart_rate`	INTEGER	Heart rate in beats per minute.
`cadence`	INTEGER	cadence in revolutions per minute.
`distance`	REAL	Cumulative distance covered so far, in meters.
`speed`	REAL	speed in meters per second.
`power`	INTEGER	power in watts.
`compressed_speed_distance`	TEXT	Speed and distance for this record, packed into a compact byte encoding rather than two separate fields. units: m/s,m; scale: 100,16.Not a per-sample series: a small fixed-size packed byte array decoding to exactly two values (speed, then distance), one scale factor per decoded value.
`grade`	REAL	grade (slope) as a percentage.
`resistance`	INTEGER	Relative. 0 is none 254 is Max.
`time_from_course`	REAL	Time ahead of or behind the course pace, in seconds.
`cycle_length`	REAL	Length of one cycle, such as one pedal revolution or stride, in meters.
`temperature`	INTEGER	temperature in degrees Celsius.
`speed1s`	TEXT	units: m/s; scale: 16; speed at 1s intervals. timestamp field indicates time of last array element.One value per second; the last element's time is this record's own timestamp field.
`cycles`	INTEGER	Total cycles at this point, such as pedal revolutions or steps.
`total_cycles`	INTEGER	Total cycles, such as pedal revolutions or steps.
`compressed_accumulated_power`	INTEGER	Accumulated power in watts, compressed encoding.
`accumulated_power`	INTEGER	Accumulated power in watts.
`left_right_balance`	INTEGER	Left/right power balance as a percentage, encoded per the FIT left_right_balance_100 type (high bit flags the measurement source).
`gps_accuracy`	INTEGER	Estimated GPS position accuracy, in meters.
`vertical_speed`	REAL	Vertical speed in meters per second.
`calories`	INTEGER	calories burned to this point in the activity, in kilocalories.
`vertical_oscillation`	REAL	Vertical oscillation in millimeters.
`stance_time_percent`	REAL	Ground contact time as a percentage of the stride cycle.
`stance_time`	REAL	Ground contact time per step, in milliseconds.
`activity_type`	INTEGER	FIT activity-type code classifying the kind of activity this sample represents, such as walking, running, or sleeping.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`left_torque_effectiveness`	REAL	Left torque effectiveness, as a percentage.
`right_torque_effectiveness`	REAL	Right torque effectiveness, as a percentage.
`left_pedal_smoothness`	REAL	Left pedal smoothness, as a percentage.
`right_pedal_smoothness`	REAL	Right pedal smoothness, as a percentage.
`combined_pedal_smoothness`	REAL	Combined pedal smoothness, as a percentage.
`time128`	REAL	Elapsed time in seconds, encoded at 1/128-second resolution.
`stroke_type`	INTEGER	Swimming stroke type recorded for this sample.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`zone`	INTEGER	Heart rate zone at this point.
`ball_speed`	REAL	Ball speed in meters per second.
`cadence256`	REAL	Log cadence and fractional cadence for backwards compatability. Units: rpm.
`fractional_cadence`	REAL	Fractional part of the cadence reading, in revolutions per minute.
`total_hemoglobin_conc`	REAL	Total saturated and unsaturated hemoglobin. Units: g/dL.
`total_hemoglobin_conc_min`	REAL	Min saturated and unsaturated hemoglobin.
`total_hemoglobin_conc_max`	REAL	Max saturated and unsaturated hemoglobin. Units: g/dL.
`saturated_hemoglobin_percent`	REAL	Percentage of hemoglobin saturated with oxygen. Units: %.
`saturated_hemoglobin_percent_min`	REAL	Min percentage of hemoglobin saturated with oxygen.
`saturated_hemoglobin_percent_max`	REAL	Max percentage of hemoglobin saturated with oxygen. Units: %.
`device_index`	INTEGER	Index identifying which connected device this data pertains to, matching a device_info record's own device_index.
`left_pco`	INTEGER	Left platform center offset. Units: mm.
`right_pco`	INTEGER	Right platform center offset. Units: mm.
`left_power_phase`	TEXT	units: degrees; scale: 0.7111111; Left power phase angles. Data value indexes defined by power_phase_type.One value per power_phase_type enum value.
`left_power_phase_peak`	TEXT	units: degrees; scale: 0.7111111; Left power phase peak angles. Data value indexes defined by power_phase_type.One value per power_phase_type enum value.
`right_power_phase`	TEXT	units: degrees; scale: 0.7111111; Right power phase angles. Data value indexes defined by power_phase_type.One value per power_phase_type enum value.
`right_power_phase_peak`	TEXT	units: degrees; scale: 0.7111111; Right power phase peak angles. Data value indexes defined by power_phase_type.One value per power_phase_type enum value.
`enhanced_speed`	REAL	speed in meters per second, extended-range encoding.
`enhanced_altitude`	REAL	Altitude at this point, in metres (extended-range counterpart to altitude).
`battery_soc`	REAL	Lev battery state of charge. Units: percent.
`motor_power`	INTEGER	Lev motor power. Units: watts.
`vertical_ratio`	REAL	Vertical ratio, as a percentage.
`stance_time_balance`	REAL	Left/right balance of ground contact time, as a percentage.
`step_length`	REAL	Step length in millimeters.
`cycle_length16`	REAL	Supports larger cycle sizes needed for paddlesports. Max cycle size: 655.35.
`absolute_pressure`	INTEGER	Includes atmospheric pressure. Units: Pa.
`depth`	REAL	0 if above water. Units: m.
`next_stop_depth`	REAL	0 if above water. Units: m.
`next_stop_time`	INTEGER	Time until the next decompression stop, in seconds.
`time_to_surface`	INTEGER	Estimated time to safely surface from the dive, in seconds.
`ndl_time`	INTEGER	No-decompression limit remaining, in seconds.
`cns_load`	INTEGER	Central nervous system oxygen toxicity load, as a percentage.
`n2_load`	INTEGER	Nitrogen loading, as a percentage.
`respiration_rate`	INTEGER	Respiration rate in breaths per minute.
`enhanced_respiration_rate`	REAL	Respiration rate in breaths per minute, extended-range encoding.
`grit`	REAL	The grit score estimates how challenging a route could be for a cyclist in terms of time spent going over sharp turns or large grade slopes.
`flow`	REAL	The flow score estimates how long distance wise a cyclist deaccelerates over intervals where deacceleration is unnecessary such as smooth turns or small grade angle intervals.
`current_stress`	REAL	Current Stress value.
`ebike_travel_range`	INTEGER	Estimated remaining e-bike range, in kilometers.
`ebike_battery_level`	INTEGER	E-bike battery level as a percentage.
`ebike_assist_mode`	INTEGER	The e-bike's current assist-power mode/level, as reported by the bike's own sensor. Units: depends on sensor.
`ebike_assist_level_percent`	INTEGER	E-bike motor assist level as a percentage.
`air_time_remaining`	INTEGER	Estimated remaining air time in seconds.
`pressure_sac`	REAL	Pressure-based surface air consumption. Units: bar/min.
`volume_sac`	REAL	Volumetric surface air consumption. Units: L/min.
`rmv`	REAL	Respiratory minute volume.
`ascent_rate`	REAL	Rate of ascent in meters per second.
`po2`	REAL	Current partial pressure of oxygen. Units: percent.
`core_temperature`	REAL	Core body temperature in degrees Celsius.

RespirationRate

Respiration rate in breaths per minute.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`respiration_rate`	REAL	Breaths * 100 /min, -300 indicates invalid, -200 indicates large motion, -100 indicates off wrist.

Schedule

A scheduled workout or course, and whether it has been started.

Field	Type	Description
`file_number`	INTEGER	The file number.
`manufacturer_id`	INTEGER	Corresponds to file_id of scheduled workout / course.
`product_id`	INTEGER	Corresponds to file_id of scheduled workout / course.
`favero_product_id`	INTEGER	Favero-specific product code identifying the device model, valid only when manufacturer_id is Favero Electronics.
`garmin_product_id`	INTEGER	Garmin-specific product code identifying the device model, valid only when manufacturer_id is Garmin.
`serial_number`	INTEGER	Corresponds to file_id of scheduled workout / course.
`time_created`	INTEGER	Matches the file_id time_created of the scheduled workout or course, in ISO8601 format.
`completed`	INTEGER	Whether this scheduled activity has been started.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`type`	INTEGER	type of scheduled item, such as workout or course.
`scheduled_time`	INTEGER	Time the workout or course is scheduled for, in ISO8601 format.

SdmProfile

Stores configuration for speed and distance monitors (footpods).

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`enabled`	INTEGER	Whether this speed and distance sensor profile is enabled.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`sdm_ant_id`	INTEGER	ANT device ID of the speed/distance sensor (footpod) paired with this profile.
`sdm_cal_factor`	REAL	Calibration factor for the speed and distance sensor, as a percentage.
`odometer`	REAL	odometer reading in meters.
`speed_source`	INTEGER	Use footpod for speed source instead of GPS.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`sdm_ant_id_trans_type`	INTEGER	ANT transmission type of the footpod identified by sdm_ant_id.
`odometer_rollover`	INTEGER	Rollover counter that can be used to extend the odometer.

SegmentFile

Summary of the unique segment and leaderboard information associated with a segment file. Used to compile a segment list file describing all segment files on a device, consulted when refreshing a segment file with the latest available leaderboard information.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`file_uuid`	TEXT	UUID of the segment file.
`enabled`	INTEGER	State of the segment file.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`user_profile_primary_key`	INTEGER	Primary key of the user that created the segment file.
`leader_type`	TEXT	Leader type of each leader in the segment file.One value per leaderboard leader, index-aligned with leader_group_primary_key/ leader_activity_id/leader_activity_id_string.
`leader_group_primary_key`	TEXT	Group primary key of each leader in the segment file.One value per leaderboard leader, index-aligned with leader_type/leader_activity_id/ leader_activity_id_string.
`leader_activity_id`	TEXT	Activity ID of each leader in the segment file.One value per leaderboard leader, index-aligned with leader_type/ leader_group_primary_key/leader_activity_id_string.
`leader_activity_id_string`	TEXT	String version of the activity ID of each leader in the segment file. 21 characters long for each ID, express in decimal.One value per leaderboard leader, index-aligned with leader_type/ leader_group_primary_key/leader_activity_id.
`default_race_leader`	INTEGER	Index for the Leader Board entry selected as the default race participant.

SegmentId

Segment_id: Unique Identification data for a segment file.

Field	Type	Description
`file_number`	INTEGER	The file number.
`Name`	TEXT	Friendly name assigned to segment.
`uuid`	TEXT	Of the segment.
`sport_id`	INTEGER	Sport associated with the segment.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`enabled`	INTEGER	Segment enabled for evaluation.Stored in SQLite as INTEGER: 0 = false, 1 = true.
`user_profile_primary_key`	INTEGER	Primary key of the user that created the segment.
`device_id`	INTEGER	ID of the device that created the segment.
`default_race_leader`	INTEGER	Index for the Leader Board entry selected as the default race participant.
`delete_status`	INTEGER	Indicates if any segments should be deleted.
`selection_type`	INTEGER	Indicates how the segment was selected to be sent to the device.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

SegmentLap

Segment_lap:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`timestamp`	TEXT	In ISO8601 format.
`event_id`	INTEGER	FIT event code identifying what triggered this record, such as a timer start/stop or a lap marker.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`event_type`	INTEGER	FIT event-type code describing how the event occurred, such as start, stop, or marker.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`start_time`	TEXT	Start time of the segment lap, in ISO8601 format.
`start_position_lat`	INTEGER	Latitude of the start position, in semicircles.
`start_position_long`	INTEGER	Longitude of the start position, in semicircles.
`end_position_lat`	INTEGER	Latitude of the end position, in semicircles.
`end_position_long`	INTEGER	Longitude of the end position, in semicircles.
`total_elapsed_time`	REAL	Time (includes pauses). Units: s.
`total_timer_time`	REAL	Timer Time (excludes pauses). Units: s.
`total_distance`	REAL	Total distance in meters.
`total_cycles`	INTEGER	Total cycles, such as pedal revolutions or steps.
`total_strokes`	INTEGER	Total number of strokes.
`total_calories`	INTEGER	Total calories burned, in kilocalories.
`total_fat_calories`	INTEGER	Total calories burned from fat, in kilocalories.
`avg_speed`	REAL	Average speed in meters per second.
`max_speed`	REAL	Maximum speed in meters per second.
`avg_heart_rate`	INTEGER	Average heart rate in beats per minute.
`max_heart_rate`	INTEGER	Maximum heart rate in beats per minute.
`avg_cadence`	INTEGER	Average cadence, in revolutions per minute -- computed by the recording device as total_cycles / total_timer_time, or total_cycles / total_elapsed_time, depending on a device setting not otherwise captured in this data.
`max_cadence`	INTEGER	Maximum cadence in revolutions per minute.
`avg_power`	INTEGER	Average power, in watts -- computed by the recording device from its own internal power total, divided by total_timer_time or total_elapsed_time depending on a device setting; neither the power total nor the setting is otherwise captured in this data.
`max_power`	INTEGER	Maximum power in watts.
`total_ascent`	INTEGER	Total ascent in meters.
`total_descent`	INTEGER	Total descent in meters.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.
`event_group`	INTEGER	Groups related events together, distinguishing concurrent event streams (such as separate segments within a multisport session) that share the same event_id and event_type.
`nec_lat`	INTEGER	North east corner latitude. Units: semicircles.
`nec_long`	INTEGER	North east corner longitude. Units: semicircles.
`swc_lat`	INTEGER	South west corner latitude. Units: semicircles.
`swc_long`	INTEGER	South west corner latitude. Units: semicircles.
`Name`	TEXT	User-assigned or generated name for this segment attempt.
`normalized_power`	INTEGER	Normalized power in watts.
`left_right_balance`	INTEGER	Left/right power balance as a percentage, encoded per the FIT left_right_balance_100 type (high bit flags the measurement source).
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.
`total_work`	INTEGER	Total work performed, in joules.
`avg_altitude`	REAL	Average altitude during this segment lap, in metres.
`max_altitude`	REAL	Maximum altitude reached during this segment lap, in metres.
`gps_accuracy`	INTEGER	Estimated GPS position accuracy, in meters.
`avg_grade`	REAL	Average grade (slope) as a percentage.
`avg_pos_grade`	REAL	Average ascending grade, as a percentage.
`avg_neg_grade`	REAL	Average descending grade, as a percentage.
`max_pos_grade`	REAL	Steepest ascending grade, as a percentage.
`max_neg_grade`	REAL	Steepest descending grade, as a percentage.
`avg_temperature`	INTEGER	Average temperature in degrees Celsius.
`max_temperature`	INTEGER	Maximum temperature in degrees Celsius.
`total_moving_time`	REAL	Total time spent moving, in seconds.
`avg_pos_vertical_speed`	REAL	Average ascending vertical speed, in meters per second.
`avg_neg_vertical_speed`	REAL	Average descending vertical speed, in meters per second.
`max_pos_vertical_speed`	REAL	Maximum ascending vertical speed, in meters per second.
`max_neg_vertical_speed`	REAL	Maximum descending vertical speed, in meters per second.
`time_in_heart_rate_zone`	TEXT	Total time spent in each heart-rate training zone during this segment lap. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_speed_zone`	TEXT	Total time spent in each speed training zone during this segment lap. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_cadence_zone`	TEXT	Total time spent in each cadence training zone during this segment lap. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_power_zone`	TEXT	Total time spent in each power training zone during this segment lap. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`repetition_number`	INTEGER	Ordinal position of this segment lap within a repeated/looped sequence of laps.
`min_altitude`	REAL	Minimum altitude reached during this segment lap, in metres.
`min_heart_rate`	INTEGER	Minimum heart rate in beats per minute.
`active_time`	REAL	Active time in seconds.
`workout_step_index`	INTEGER	Index of the workout_step (in the parent Workout) that produced this record, when generated by a structured workout.
`sport_event`	INTEGER	Sport-specific event classification for this segment lap, such as an uphill or descent segment.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`avg_left_torque_effectiveness`	REAL	Average left torque effectiveness, as a percentage.
`avg_right_torque_effectiveness`	REAL	Average right torque effectiveness, as a percentage.
`avg_left_pedal_smoothness`	REAL	Average left pedal smoothness, as a percentage.
`avg_right_pedal_smoothness`	REAL	Average right pedal smoothness, as a percentage.
`avg_combined_pedal_smoothness`	REAL	Average combined pedal smoothness, as a percentage.
`status`	INTEGER	Status of the segment attempt, such as completed.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`uuid`	TEXT	Unique identifier of the segment.
`avg_fractional_cadence`	REAL	Fractional part of the avg_cadence. Units: rpm.
`max_fractional_cadence`	REAL	Fractional part of the max_cadence. Units: rpm.
`total_fractional_cycles`	REAL	Fractional part of the total_cycles. Units: cycles.
`front_gear_shift_count`	INTEGER	Number of front-derailleur gear shifts during this segment.
`rear_gear_shift_count`	INTEGER	Number of rear-derailleur gear shifts during this segment.
`time_standing`	REAL	Total time spent in the standing position. Units: s.
`stand_count`	INTEGER	Number of transitions to the standing state.
`avg_left_pco`	INTEGER	Average left platform center offset. Units: mm.
`avg_right_pco`	INTEGER	Average right platform center offset. Units: mm.
`avg_left_power_phase`	TEXT	Average left-leg pedal-stroke power-phase angles, in degrees of crank rotation -- the portion of each pedal stroke where meaningful force is applied. Each of the 4 array elements is a different measurement of that phase (start angle, end angle, arc length, center), per power_phase_type.One value per power_phase_type enum value.
`avg_left_power_phase_peak`	TEXT	As avg_left_power_phase, but for the power phase during this segment lap's single hardest effort rather than averaged across the whole segment lap.One value per power_phase_type enum value.
`avg_right_power_phase`	TEXT	As avg_left_power_phase, for the right leg.One value per power_phase_type enum value.
`avg_right_power_phase_peak`	TEXT	As avg_left_power_phase_peak, for the right leg.One value per power_phase_type enum value.
`avg_power_position`	TEXT	Average power, in watts, broken out by rider position (seated, standing, or transitioning between them) -- one value per rider_position_type.One value per rider_position_type enum value.
`max_power_position`	TEXT	As avg_power_position, but the maximum power reached rather than the average.One value per rider_position_type enum value.
`avg_cadence_position`	TEXT	Average cadence, in revolutions per minute, broken out by rider position (seated, standing, or transitioning between them).One value per rider_position_type enum value.
`max_cadence_position`	TEXT	As avg_cadence_position, but the maximum cadence reached rather than the average.One value per rider_position_type enum value.
`manufacturer_id`	INTEGER	Manufacturer that produced the segment.
`total_grit`	REAL	The grit score estimates how challenging a route could be for a cyclist in terms of time spent going over sharp turns or large grade slopes. Units: kGrit.
`total_flow`	REAL	The flow score estimates how long distance wise a cyclist deaccelerates over intervals where deacceleration is unnecessary such as smooth turns or small grade angle intervals. Units: Flow.
`avg_grit`	REAL	The grit score estimates how challenging a route could be for a cyclist in terms of time spent going over sharp turns or large grade slopes. Units: kGrit.
`avg_flow`	REAL	The flow score estimates how long distance wise a cyclist deaccelerates over intervals where deacceleration is unnecessary such as smooth turns or small grade angle intervals. Units: Flow.
`total_fractional_ascent`	REAL	Fractional part of total_ascent. Units: m.
`total_fractional_descent`	REAL	units: m; scale: 100; fractional part of total_descent.
`enhanced_avg_altitude`	REAL	Average altitude during this segment lap, in metres (extended-range counterpart to avg_altitude).
`enhanced_max_altitude`	REAL	Maximum altitude reached during this segment lap, in metres (extended-range counterpart to max_altitude).
`enhanced_min_altitude`	REAL	Minimum altitude reached during this segment lap, in metres (extended-range counterpart to min_altitude).

SegmentLeaderboardEntry

Segment_leaderboard_entry: Unique Identification data for an individual segment leader within a segment file.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`Name`	TEXT	Friendly name assigned to leader.
`type`	INTEGER	Leader classification.
`group_primary_key`	INTEGER	Primary user ID of this leader.
`activity_id`	INTEGER	ID of the activity associated with this leader time.
`segment_time`	REAL	units: s; scale: 1000; Segment Time (includes pauses).
`activity_id_string`	TEXT	String version of the activity_id. 21 characters long, express in decimal.

SegmentPoint

Segment_point: Navigation and race evaluation point for a segment decribing a point along the segment path and time it took each segment leader to reach that point.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`position_lat`	INTEGER	Latitude in semicircles.
`position_long`	INTEGER	Longitude in semicircles.
`distance`	REAL	Accumulated distance along the segment at the described point. Units: m.
`altitude`	REAL	Offset: 500; Accumulated altitude along the segment at the described point. Units: m.
`leader_time`	TEXT	units: s; scale: 1000; Accumualted time each leader board member required to reach the described point. This value is zero for all leader board members at the starting point of the segment.One value per leaderboard leader, in the same leader order as SegmentFile's leader_type/leader_group_primary_key/leader_activity_id arrays.
`enhanced_altitude`	REAL	Offset: 500; Accumulated altitude along the segment at the described point. Units: m.

Session

Represents a single workout or activity session with detailed metrics.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Selected bit is set for the current session.
`timestamp`	TEXT	In ISO8601 format.
`event_id`	INTEGER	Type of event; always ‘session’ for this message.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`event_type`	INTEGER	Event type; always ‘stop’ for this message, marking the end of the session.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`start_time`	TEXT	Start time of the session, in ISO8601 format.
`start_position_lat`	INTEGER	Latitude of the start position, in semicircles.
`start_position_long`	INTEGER	Longitude of the start position, in semicircles.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`total_elapsed_time`	REAL	Time (includes pauses). Units: s.
`total_timer_time`	REAL	Timer Time (excludes pauses). Units: s.
`total_distance`	REAL	Total distance in meters.
`total_cycles`	INTEGER	Total cycles, such as pedal revolutions or steps.
`total_strides`	INTEGER	Total number of strides.
`total_strokes`	INTEGER	Total number of strokes.
`total_calories`	INTEGER	Total calories burned, in kilocalories.
`total_fat_calories`	INTEGER	Total calories burned from fat, in kilocalories.
`avg_speed`	REAL	Total_distance / total_timer_time. Units: m/s.
`max_speed`	REAL	Maximum speed in meters per second.
`avg_heart_rate`	INTEGER	Average heart rate (excludes pause time). Units: bpm.
`max_heart_rate`	INTEGER	Maximum heart rate in beats per minute.
`avg_cadence`	INTEGER	Average cadence, in revolutions per minute -- computed by the recording device as total_cycles / total_timer_time, or total_cycles / total_elapsed_time, depending on a device setting not otherwise captured in this data.
`avg_running_cadence`	INTEGER	Average running cadence in strides per minute.
`max_cadence`	INTEGER	Maximum cadence in revolutions per minute.
`max_running_cadence`	INTEGER	Maximum running cadence in strides per minute.
`avg_power`	INTEGER	Average power, in watts -- computed by the recording device from its own internal power total, divided by total_timer_time or total_elapsed_time depending on a device setting; neither the power total nor the setting is otherwise captured in this data.
`max_power`	INTEGER	Maximum power in watts.
`total_ascent`	INTEGER	Total ascent in meters.
`total_descent`	INTEGER	Total descent in meters.
`total_training_effect`	REAL	Aerobic training effect score for the session.
`first_lap_index`	INTEGER	Index of the first lap (in the parent Activity's laps) belonging to this session.
`number_laps`	INTEGER	Num Laps.
`event_group`	INTEGER	Groups related events together, distinguishing concurrent event streams (such as separate segments within a multisport session) that share the same event_id and event_type.
`trigger`	INTEGER	What triggered the end of the session, such as a manual stop or auto-lap.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`nec_lat`	INTEGER	North east corner latitude. Units: semicircles.
`nec_long`	INTEGER	North east corner longitude. Units: semicircles.
`swc_lat`	INTEGER	South west corner latitude. Units: semicircles.
`swc_long`	INTEGER	South west corner longitude. Units: semicircles.
`number_lengths`	INTEGER	# of lengths of swim pool.
`normalized_power`	INTEGER	Normalized power in watts.
`training_stress_score`	REAL	Training stress score (TSS).
`intensity_factor`	REAL	Intensity factor — normalized power as a fraction of functional threshold power.
`left_right_balance`	INTEGER	Left/right power balance as a percentage, encoded per the FIT left_right_balance_100 type (high bit flags the measurement source).
`end_position_lat`	INTEGER	Latitude of the end position, in semicircles.
`end_position_long`	INTEGER	Longitude of the end position, in semicircles.
`avg_stroke_count`	REAL	Average strokes per lap.
`avg_stroke_distance`	REAL	Average distance covered per stroke, in meters.
`swim_stroke`	INTEGER	Swimming stroke type used.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`pool_length`	REAL	Pool length in meters.
`threshold_power`	INTEGER	Functional threshold power in watts.
`pool_length_unit`	INTEGER	Unit (metric or statute) in which pool_length is expressed.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`number_active_lengths`	INTEGER	# of active lengths of swim pool.
`total_work`	INTEGER	Total work performed, in joules.
`avg_altitude`	REAL	Average altitude during this session, in metres.
`max_altitude`	REAL	Maximum altitude reached during this session, in metres.
`gps_accuracy`	INTEGER	Estimated GPS position accuracy, in meters.
`avg_grade`	REAL	Average grade (slope) as a percentage.
`avg_pos_grade`	REAL	Average ascending grade, as a percentage.
`avg_neg_grade`	REAL	Average descending grade, as a percentage.
`max_pos_grade`	REAL	Steepest ascending grade, as a percentage.
`max_neg_grade`	REAL	Steepest descending grade, as a percentage.
`avg_temperature`	INTEGER	Average temperature in degrees Celsius.
`max_temperature`	INTEGER	Maximum temperature in degrees Celsius.
`total_moving_time`	REAL	Total time spent moving, in seconds.
`avg_pos_vertical_speed`	REAL	Average ascending vertical speed, in meters per second.
`avg_neg_vertical_speed`	REAL	Average descending vertical speed, in meters per second.
`max_pos_vertical_speed`	REAL	Maximum ascending vertical speed, in meters per second.
`max_neg_vertical_speed`	REAL	Maximum descending vertical speed, in meters per second.
`min_heart_rate`	INTEGER	Minimum heart rate in beats per minute.
`time_in_heart_rate_zone`	TEXT	Total time spent in each heart-rate training zone during this session. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_speed_zone`	TEXT	Total time spent in each speed training zone during this session. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_cadence_zone`	TEXT	Total time spent in each cadence training zone during this session. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`time_in_power_zone`	TEXT	Total time spent in each power training zone during this session. units: s; scale: 1000.One value per zone; the zone boundaries themselves are recorded in this activity's ZonesTarget/TimeInZone record, not here.
`avg_lap_time`	REAL	Average lap time in seconds.
`best_lap_index`	INTEGER	Index of the fastest lap in this session.
`min_altitude`	REAL	Minimum altitude reached during this session, in metres.
`player_score`	INTEGER	This user's own score in games or sports with a scoring system, such as squash or racquetball.
`opponent_score`	INTEGER	Opponent's score in games or sports with an adversarial scoring system, such as squash or racquetball.
`opponent_name`	TEXT	Name of the opponent, for games or sports with an adversarial scoring system.
`stroke_count`	TEXT	Number of times each swimming stroke type was used.One value per stroke_type enum value.
`zone_count`	TEXT	Count recorded for each zone.One value per zone.
`max_ball_speed`	REAL	Maximum ball speed in meters per second.
`avg_ball_speed`	REAL	Average ball speed in meters per second.
`avg_vertical_oscillation`	REAL	Average vertical oscillation in millimeters.
`avg_stance_time_percent`	REAL	Average ground contact time as a percentage of the stride cycle.
`avg_stance_time`	REAL	Average ground contact time per step, in milliseconds.
`avg_fractional_cadence`	REAL	Fractional part of the avg_cadence. Units: rpm.
`max_fractional_cadence`	REAL	Fractional part of the max_cadence. Units: rpm.
`total_fractional_cycles`	REAL	Fractional part of the total_cycles. Units: cycles.
`avg_total_hemoglobin_conc`	TEXT	units: g/dL; scale: 100; Avg saturated and unsaturated hemoglobin.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`min_total_hemoglobin_conc`	TEXT	units: g/dL; scale: 100; Min saturated and unsaturated hemoglobin.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`max_total_hemoglobin_conc`	TEXT	units: g/dL; scale: 100; Max saturated and unsaturated hemoglobin.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`avg_saturated_hemoglobin_percent`	TEXT	units: %; scale: 10; Avg percentage of hemoglobin saturated with oxygen.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`min_saturated_hemoglobin_percent`	TEXT	units: %; scale: 10; Min percentage of hemoglobin saturated with oxygen.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`max_saturated_hemoglobin_percent`	TEXT	units: %; scale: 10; Max percentage of hemoglobin saturated with oxygen.One value per connected muscle-oxygen (SmO2) sensor, when more than one is paired.
`avg_left_torque_effectiveness`	REAL	Average left torque effectiveness, as a percentage.
`avg_right_torque_effectiveness`	REAL	Average right torque effectiveness, as a percentage.
`avg_left_pedal_smoothness`	REAL	Average left pedal smoothness, as a percentage.
`avg_right_pedal_smoothness`	REAL	Average right pedal smoothness, as a percentage.
`avg_combined_pedal_smoothness`	REAL	Average combined pedal smoothness, as a percentage.
`sport_profile_name`	TEXT	Sport name from associated sport mesg.
`sport_index`	INTEGER	Zero-based ordinal identifying which sport segment, within a multisport activity, this record belongs to.
`time_standing`	REAL	Total time spend in the standing position. Units: s.
`stand_count`	INTEGER	Number of transitions to the standing state.
`avg_left_pco`	INTEGER	Average platform center offset Left. Units: mm.
`avg_right_pco`	INTEGER	Average platform center offset Right. Units: mm.
`avg_left_power_phase`	TEXT	Average left-leg pedal-stroke power-phase angles, in degrees of crank rotation -- the portion of each pedal stroke where meaningful force is applied. Each of the 4 array elements is a different measurement of that phase (start angle, end angle, arc length, center), per power_phase_type.One value per power_phase_type enum value.
`avg_left_power_phase_peak`	TEXT	As avg_left_power_phase, but for the power phase during this session's single hardest effort rather than averaged across the whole session.One value per power_phase_type enum value.
`avg_right_power_phase`	TEXT	As avg_left_power_phase, for the right leg.One value per power_phase_type enum value.
`avg_right_power_phase_peak`	TEXT	As avg_left_power_phase_peak, for the right leg.One value per power_phase_type enum value.
`avg_power_position`	TEXT	Average power, in watts, broken out by rider position (seated, standing, or transitioning between them) -- one value per rider_position_type.One value per rider_position_type enum value.
`max_power_position`	TEXT	As avg_power_position, but the maximum power reached rather than the average.One value per rider_position_type enum value.
`avg_cadence_position`	TEXT	Average cadence, in revolutions per minute, broken out by rider position (seated, standing, or transitioning between them).One value per rider_position_type enum value.
`max_cadence_position`	TEXT	As avg_cadence_position, but the maximum cadence reached rather than the average.One value per rider_position_type enum value.
`enhanced_avg_speed`	REAL	Total_distance / total_timer_time. Units: m/s.
`enhanced_max_speed`	REAL	Maximum speed in meters per second, extended-range encoding.
`enhanced_avg_altitude`	REAL	Average altitude during this session, in metres (extended-range counterpart to avg_altitude).
`enhanced_min_altitude`	REAL	Minimum altitude reached during this session, in metres (extended-range counterpart to min_altitude).
`enhanced_max_altitude`	REAL	Maximum altitude reached during this session, in metres (extended-range counterpart to max_altitude).
`avg_lev_motor_power`	INTEGER	Lev average motor power during session. Units: watts.
`max_lev_motor_power`	INTEGER	Lev maximum motor power during session. Units: watts.
`lev_battery_consumption`	REAL	Lev battery consumption during session. Units: percent.
`avg_vertical_ratio`	REAL	Average vertical ratio, as a percentage.
`avg_stance_time_balance`	REAL	Average left/right balance of ground contact time, as a percentage.
`avg_step_length`	REAL	Average step length in millimeters.
`total_anaerobic_training_effect`	REAL	Anaerobic training effect score for the session.
`avg_vam`	REAL	Average ascent speed (VAM) in meters per second.
`avg_depth`	REAL	0 if above water. Units: m.
`max_depth`	REAL	0 if above water. Units: m.
`surface_interval`	INTEGER	Time since end of last dive. Units: s.
`start_cns`	INTEGER	CNS oxygen toxicity load at the start of the dive, as a percentage.
`end_cns`	INTEGER	CNS oxygen toxicity load at the end of the dive, as a percentage.
`start_n2`	INTEGER	Nitrogen loading at the start of the dive, as a percentage.
`end_n2`	INTEGER	Nitrogen loading at the end of the dive, as a percentage.
`avg_respiration_rate`	INTEGER	Average respiration rate during this period, in breaths per minute; superseded by the wider-range enhanced_avg_respiration_rate where present.
`max_respiration_rate`	INTEGER	Maximum respiration rate during this period, in breaths per minute; superseded by the wider-range enhanced_max_respiration_rate where present.
`min_respiration_rate`	INTEGER	Minimum respiration rate during this session, in breaths per minute; superseded by the wider-range enhanced_min_respiration_rate where present.
`min_temperature`	INTEGER	Minimum temperature in degrees Celsius.
`o2_toxicity`	INTEGER	Oxygen toxicity load, in OTUs (oxygen toxicity units).
`dive_number`	INTEGER	Number identifying this dive within a multi-dive activity file, when applicable.
`training_load_peak`	REAL	Peak training load value.
`enhanced_avg_respiration_rate`	REAL	Average respiration rate in breaths per minute.
`enhanced_max_respiration_rate`	REAL	Maximum respiration rate in breaths per minute.
`enhanced_min_respiration_rate`	REAL	Minimum respiration rate in breaths per minute.
`total_grit`	REAL	The grit score estimates how challenging a route could be for a cyclist in terms of time spent going over sharp turns or large grade slopes. Units: kGrit.
`total_flow`	REAL	The flow score estimates how long distance wise a cyclist deaccelerates over intervals where deacceleration is unnecessary such as smooth turns or small grade angle intervals. Units: Flow.
`jump_count`	INTEGER	Number of jumps detected during this period, such as skiing or snowboarding jumps.
`avg_grit`	REAL	The grit score estimates how challenging a route could be for a cyclist in terms of time spent going over sharp turns or large grade slopes. Units: kGrit.
`avg_flow`	REAL	The flow score estimates how long distance wise a cyclist deaccelerates over intervals where deacceleration is unnecessary such as smooth turns or small grade angle intervals. Units: Flow.
`workout_feel`	INTEGER	A 0-100 scale representing how a user felt while performing a workout. Low values are considered feeling bad, while high values are good.
`workout_rpe`	INTEGER	Common Borg CR10 / 0-10 RPE scale, multiplied 10x. Aggregate score for all workouts in a single session.
`avg_spo2`	INTEGER	Average SPO2 for the monitoring session. Units: percent.
`avg_stress`	INTEGER	Average stress for the monitoring session. Units: percent.
`sdrr_hrv`	INTEGER	Standard deviation of R-R interval (SDRR) - Heart rate variability measure most useful for wellness users. Units: mS.
`rmssd_hrv`	INTEGER	Root mean square successive difference (RMSSD) - Heart rate variability measure most useful for athletes. Units: mS.
`total_fractional_ascent`	REAL	Fractional part of total_ascent. Units: m.
`total_fractional_descent`	REAL	Fractional part of total_descent. Units: m.
`avg_core_temperature`	REAL	Average core body temperature in degrees Celsius.
`min_core_temperature`	REAL	Minimum core body temperature in degrees Celsius.
`max_core_temperature`	REAL	Maximum core body temperature in degrees Celsius.
`total_reps`	INTEGER	Total number of repetitions.A subfield of the FIT total_cycles field, active when sub_sport is strength_training or sport is hiit.
`total_pushes`	INTEGER	Total number of pushes in a session.A subfield of the FIT total_cycles field, active when sport is wheelchair_push_run or wheelchair_push_walk.

SetX

Represents a strength training set including repetitions, weight, and duration.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Timestamp of the set, in ISO8601 format.
`duration`	INTEGER	duration of the set, in seconds.
`repetitions`	INTEGER	# of repitions of the movement.
`weight`	INTEGER	Amount of weight applied for the set. Units: kg.
`set_type`	INTEGER	SetX Type.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`start_time`	TEXT	Start time of the set, in ISO8601 format.
`raw_category_garmin_key`	TEXT	Raw FIT exercise_category[0] code for this set's exercise, e.g. "7". Stored verbatim, not resolved.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`raw_category_subtype_garmin_key`	TEXT	Raw FIT exercise_category[0] + exercise_name[0] codes, space-separated the same way NumericVectorToText formats a compound value, e.g. "7 2" -- present only when this set's exercise has a specific catalogued subtype (e.g. "Lat Pulldown" rather than just "Pull Up"); empty otherwise.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`weight_display_unit`	INTEGER	Unit (such as kilograms or pounds) the weight field should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`workout_step_index`	INTEGER	Index of the workout_step (in the parent Workout) that produced this record, when generated by a structured workout.

SkinTempOvernight

Skin_temp_overnight:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`local_timestamp`	TEXT	Local timestamp, in ISO8601 format.
`average_deviation`	REAL	The average overnight deviation from baseline temperature in degrees C.
`average7_day_deviation`	REAL	The average 7 day overnight deviation from baseline temperature in degrees C.
`nightly_value`	REAL	Final overnight temperature value.

SlaveDevice

Lists connected peripheral devices such as sensors or accessories.

Field	Type	Description
`file_number`	INTEGER	The file number.
`manufacturer_id`	INTEGER	FIT manufacturer code identifying the device maker, such as Garmin or a third-party partner.
`product_id`	INTEGER	Manufacturer-specific product code identifying the device model; interpreted via garmin_product_id or favero_product_id when the manufacturer defines its own product-code table.
`favero_product_id`	INTEGER	Favero-specific product code identifying the device model, valid only when manufacturer_id is Favero Electronics.
`garmin_product_id`	INTEGER	Garmin-specific product code identifying the device model, valid only when manufacturer_id is Garmin.

SleepAssessment

Sleep-quality assessment scores for a single night's sleep, as computed by the device.

Field	Type	Description
`file_number`	INTEGER	The file number.
`combined_awake_score`	INTEGER	Average of awake_time_score and awakenings_count_score. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`awake_time_score`	INTEGER	Score that evaluates the total time spent awake between sleep. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`awakenings_count_score`	INTEGER	Score that evaluates the number of awakenings that interrupt sleep. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`deep_sleep_score`	INTEGER	Score that evaluates the amount of deep sleep. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`sleep_duration_score`	INTEGER	Score that evaluates the quality of sleep based on sleep stages, heart-rate variability and possible awakenings during the night. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`light_sleep_score`	INTEGER	Score that evaluates the amount of light sleep. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`overall_sleep_score`	INTEGER	Total score that summarizes the overall quality of sleep, combining sleep duration and quality. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`sleep_quality_score`	INTEGER	Score that evaluates the quality of sleep based on sleep stages, heart-rate variability and possible awakenings during the night. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`sleep_recovery_score`	INTEGER	Score that evaluates stress and recovery during sleep. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`rem_sleep_score`	INTEGER	Score that evaluates the amount of REM sleep. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`sleep_restlessness_score`	INTEGER	Score that evaluates the amount of restlessness during sleep. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`awakenings_count`	INTEGER	The number of awakenings during sleep.
`interruptions_score`	INTEGER	Score that evaluates the sleep interruptions. If valid: 0 (worst) to 100 (best).If unknown, no score is recorded.
`average_stress_during_sleep`	REAL	Excludes stress during awake periods in the sleep window.

SleepDisruptionOvernightSeverity

Sleep_disruption_overnight_severity:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`severity`	INTEGER	severity level of the sleep disruption.

SleepDisruptionSeverityPeriod

Sleep_disruption_severity_period:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`timestamp`	TEXT	In ISO8601 format.
`severity`	INTEGER	severity level of the sleep disruption.

SleepLevel

One classified period of a sleep session (e.g. light, deep, or REM sleep).

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`SleepLevel`	INTEGER	FIT sleep-level code classifying this period, such as light, deep, or REM sleep.

Software

contains version information for the device firmware or software.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	The message index.
`version`	REAL	Software version number.
`part_number`	TEXT	The part number.

SpeedZone

Defines speed training zones.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`high_value`	REAL	Upper boundary of this speed zone, in meters per second.
`Name`	TEXT	User-assigned name for this speed zone.

Split

A user-marked or auto-detected split within an activity (e.g. an ascent, descent, or interval), with its own elapsed time, distance, and speed.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`split_type`	INTEGER	FIT split-type code classifying this split, such as ascent, descent, or interval active/rest.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`total_elapsed_time`	REAL	Total elapsed time, including pauses, in seconds.
`total_timer_time`	REAL	Total timer time, excluding pauses, in seconds.
`total_distance`	REAL	Total distance in meters.
`avg_speed`	REAL	Average speed in meters per second.
`start_time`	TEXT	Start time of the split, in ISO8601 format.
`total_ascent`	INTEGER	Total ascent in meters.
`total_descent`	INTEGER	Total descent in meters.
`start_position_lat`	INTEGER	Latitude of the start position, in semicircles.
`start_position_long`	INTEGER	Longitude of the start position, in semicircles.
`end_position_lat`	INTEGER	Latitude of the end position, in semicircles.
`end_position_long`	INTEGER	Longitude of the end position, in semicircles.
`max_speed`	REAL	Maximum speed in meters per second.
`avg_vert_speed`	REAL	Average vertical speed in meters per second.
`end_time`	TEXT	End time of the split, in ISO8601 format.
`total_calories`	INTEGER	Total calories burned, in kilocalories.
`start_elevation`	REAL	Elevation at the start of this split, in metres.
`total_moving_time`	REAL	Total time spent moving, in seconds.

SplitSummary

Split_summary:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`split_type`	INTEGER	FIT split-type code classifying this split, such as ascent, descent, or interval active/rest.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`number_splits`	INTEGER	Number of splits included in this summary.
`total_timer_time`	REAL	Total timer time, excluding pauses, in seconds.
`total_distance`	REAL	Total distance in meters.
`avg_speed`	REAL	Average speed in meters per second.
`max_speed`	REAL	Maximum speed in meters per second.
`total_ascent`	INTEGER	Total ascent in meters.
`total_descent`	INTEGER	Total descent in meters.
`avg_heart_rate`	INTEGER	Average heart rate in beats per minute.
`max_heart_rate`	INTEGER	Maximum heart rate in beats per minute.
`avg_vert_speed`	REAL	Average vertical speed in meters per second.
`total_calories`	INTEGER	Total calories burned, in kilocalories.
`total_moving_time`	REAL	Total time spent moving, in seconds.

Spo2Data

Spo2_data:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`reading_spo2`	INTEGER	Blood oxygen saturation (SpO2) reading, as a percentage.
`reading_confidence`	INTEGER	Confidence level of the pulse oximeter reading.
`mode`	INTEGER	When data was captured.

Sport

Names the sport type and sub-type associated with the activity.

Field	Type	Description
`file_number`	INTEGER	The file number.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`Name`	TEXT	User-assigned or generated display name for this sport.

StressLevel

Stress_level: Value from 1 to 100 calculated by FirstBeat.

Field	Type	Description
`file_number`	INTEGER	The file number.
`stress_level_value`	INTEGER	Calculated stress score, on a scale from 1 to 100.
`stress_level_time`	TEXT	Time stress score was calculated, in ISO8601 format.

TankSummary

Tank_summary:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`sensor`	INTEGER	ANT+ device ID of the tank pressure sensor.
`start_pressure`	REAL	Tank pressure at the start of the dive, in bar.
`end_pressure`	REAL	Tank pressure at the end of the dive, in bar.
`volume_used`	REAL	Volume of gas used, in liters.

TankUpdate

Tank_update:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`sensor`	INTEGER	ANT+ device ID of the tank pressure sensor.
`pressure`	REAL	Tank pressure in bar.

ThreeDSensorCalibration

Stores calibration data for 3D sensors such as accelerometers and gyroscopes.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Whole second part of the timestamp, in ISO8601 format.
`sensor_type`	INTEGER	Indicates which sensor the calibration is for.
`calibration_factor`	INTEGER	Calibration factor used to convert from raw ADC value to degrees, g, etc.
`accel_cal_factor`	INTEGER	Accelerometer calibration factor. Units: g.
`gyro_cal_factor`	INTEGER	Gyro calibration factor. Units: deg/s.
`calibration_divisor`	INTEGER	Calibration factor divisor. Units: counts.
`level_shift`	INTEGER	Level shift value used to shift the ADC value back into range.
`offset_cal`	TEXT	Internal calibration factors, one for each: xy, yx, zx.One value per axis pair, in this fixed order: xy, yx, zx.
`orientation_matrix`	TEXT	scale: 65535; 3 x 3 rotation matrix (row major).One value per matrix cell, row-major: indices 0-2 are row 0, 3-5 are row 1, 6-8 are row 2.

TimeInZone

Tracks time spent in various training zones such as heart rate, speed, and power.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`reference_mesg`	INTEGER	Reference Message.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`reference_index`	INTEGER	Index of the specific referenced record (paired with reference_mesg, which identifies its message type).
`time_in_heart_rate_zone`	TEXT	Total time spent in each heart-rate training zone. units: s; scale: 1000.One value per zone, index-aligned with heart_rate_zone_high_boundary.
`time_in_speed_zone`	TEXT	Total time spent in each speed training zone. units: s; scale: 1000.One value per zone, index-aligned with speed_zone_high_boundary.
`time_in_cadence_zone`	TEXT	Total time spent in each cadence training zone. units: s; scale: 1000.One value per zone, index-aligned with cadence_zone_high_bondary.
`time_in_power_zone`	TEXT	Total time spent in each power training zone. units: s; scale: 1000.One value per zone, index-aligned with power_zone_high_boundary.
`heart_rate_zone_high_boundary`	TEXT	Upper heart-rate boundary of this zone, in beats per minute.One value per zone, index-aligned with time_in_heart_rate_zone.
`speed_zone_high_boundary`	TEXT	Upper speed boundary of this zone. units: m/s; scale: 1000.One value per zone, index-aligned with time_in_speed_zone.
`cadence_zone_high_bondary`	TEXT	Upper cadence boundary of this zone, in revolutions per minute.One value per zone, index-aligned with time_in_cadence_zone.
`power_zone_high_boundary`	TEXT	Upper power boundary of this zone, in watts.One value per zone, index-aligned with time_in_power_zone.
`heart_rate_calc_type`	INTEGER	FIT heart-rate-zone calculation method, such as percent of max heart rate or percent of heart rate reserve.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`max_heart_rate`	INTEGER	Maximum heart rate used as the basis for computing heart-rate zones, in beats per minute.
`resting_heart_rate`	INTEGER	Resting heart rate used as the basis for computing heart-rate zones, in beats per minute.
`threshold_heart_rate`	INTEGER	Heart-rate threshold (LTHR) used as the basis for computing heart-rate zones via the percent-of-threshold method.
`pwr_calc_type`	INTEGER	Power Calc Type.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`functional_threshold_power`	INTEGER	Functional threshold power (FTP) used as the basis for computing power zones, in watts.

TimestampCorrelation

Provides mapping between system time and UTC time for synchronization.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Whole second part of the UTC timestamp at the time the system timestamp was recorded, in ISO8601 format.
`fractional_timestamp`	REAL	Fractional part of the UTC timestamp at the time the system timestamp was recorded. Units: s.
`system_timestamp`	TEXT	Whole second part of the system timestamp, in ISO8601 format.
`fractional_system_timestamp`	REAL	Fractional part of the system timestamp. Units: s.
`local_timestamp`	TEXT	Timestamp epoch expressed in local time, in ISO8601 format, used to convert timestamps to local time.
`timestamp_ms`	INTEGER	Millisecond part of the UTC timestamp at the time the system timestamp was recorded.
`system_timestamp_ms`	INTEGER	Millisecond part of the system timestamp.

Totals

Cumulative activity totals (distance, calories, time, session count) for one sport, accumulated since the device's last reset.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`timestamp`	TEXT	In ISO8601 format.
`timer_time`	INTEGER	Total moving/recording time accumulated across all sessions counted in this Totals record, excluding paused periods. Units: s.
`distance`	INTEGER	Total distance accumulated, in meters.
`calories`	INTEGER	Total calories burned, in kilocalories.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.
`elapsed_time`	INTEGER	Total time accumulated across all sessions counted in this Totals record, including paused periods. Units: s.
`sessions`	INTEGER	Total number of sessions.
`active_time`	INTEGER	Active time in seconds.
`sport_index`	INTEGER	Zero-based ordinal identifying which sport segment, within a multisport activity, this record belongs to.

TrainingFile

Corresponds to FileID for a file whose type is workout or course.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`type`	INTEGER	FIT file type identifying what kind of file this is (activity, workout, course, settings, etc.) -- see the FileTypeLookup table for the full code-to-description mapping.
`manufacturer_id`	INTEGER	FIT manufacturer code identifying the device maker, such as Garmin or a third-party partner.
`product_id`	INTEGER	Manufacturer-specific product code identifying the device model; interpreted via garmin_product_id or favero_product_id when the manufacturer defines its own product-code table.
`favero_product_id`	INTEGER	Favero-specific product code identifying the device model, valid only when manufacturer_id is Favero Electronics.
`garmin_product_id`	INTEGER	Garmin-specific product code identifying the device model, valid only when manufacturer_id is Garmin.
`serial_number`	INTEGER	Serial number of the device, when available.
`time_created`	INTEGER	Time the training file was created, in ISO8601 format.

TrainingSettings

Stores target metrics for structured workouts such as distance, speed, and time.

Field	Type	Description
`file_number`	INTEGER	The file number.
`target_distance`	REAL	Target distance in meters.
`target_speed`	REAL	Target speed in meters per second.
`target_time`	INTEGER	Target time in seconds.
`precise_target_speed`	REAL	A more precise target speed field. Units: m/s.

UserProfile

contains personal user data such as age, weight, height, and fitness preferences.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`friendly_name`	TEXT	Used for Morning Report greeting.
`gender`	INTEGER	User's gender.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`age`	INTEGER	User's age in years.
`height`	REAL	User's height in meters.
`weight`	REAL	User's weight in kilograms.
`language`	INTEGER	User's preferred language.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`elev_setting`	INTEGER	Unit (such as meters or feet) elevation values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`weight_setting`	INTEGER	Unit (such as kilograms or pounds) weight values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`resting_heart_rate`	INTEGER	Resting heart rate in beats per minute.
`default_max_running_heart_rate`	INTEGER	Default maximum heart rate for running, in beats per minute.
`default_max_biking_heart_rate`	INTEGER	Default maximum heart rate for biking, in beats per minute.
`default_max_heart_rate`	INTEGER	Default maximum heart rate, in beats per minute.
`heart_rate_setting`	INTEGER	Display mode for heart rate values, such as raw beats per minute or percent of max heart rate.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`speed_setting`	INTEGER	Unit (such as km/h or mph) speed values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`dist_setting`	INTEGER	Unit (such as kilometers or miles) distance values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`power_setting`	INTEGER	Unit power values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`activity_class`	INTEGER	Classification of the user's overall activity level, used to tune calorie and training estimates.
`position_setting`	INTEGER	Coordinate format (such as degrees-minutes-seconds or decimal degrees) position values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`temperature_setting`	INTEGER	Unit (such as Celsius or Fahrenheit) temperature values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`local_id`	INTEGER	Identifier for this user profile that is unique within the device, not globally.
`global_id`	TEXT	Globally-unique identifier for this user, used to correlate profiles across devices.One byte per element of this identifier.
`wake_time`	TEXT	Typical wake time.
`sleep_time`	TEXT	Typical bed time.
`height_setting`	INTEGER	Unit (such as meters or feet/inches) height values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`user_running_step_length`	REAL	User defined running step length set to 0 for auto length.
`user_walking_step_length`	REAL	User defined walking step length set to 0 for auto length.
`depth_setting`	INTEGER	Unit (such as meters or feet) dive-depth values should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`dive_count`	INTEGER	Total number of dives logged for this user.

Video

Stores metadata for a video associated with an activity.

Field	Type	Description
`file_number`	INTEGER	The file number.
`url`	TEXT	URL where the video can be retrieved.
`hosting_provider`	TEXT	Service hosting the video, such as YouTube.
`duration`	INTEGER	Playback time of video. Units: ms.

VideoClip

Represents a segment of a video associated with an activity.

Field	Type	Description
`file_number`	INTEGER	The file number.
`clip_number`	INTEGER	Index identifying this clip among other clips in the same video.
`start_timestamp`	TEXT	Start time of the video clip, in ISO8601 format.
`start_timestamp_ms`	INTEGER	Fractional-second part of start_timestamp, in milliseconds.
`end_timestamp`	TEXT	End time of the video clip, in ISO8601 format.
`end_timestamp_ms`	INTEGER	Fractional-second part of end_timestamp, in milliseconds.
`clip_start`	INTEGER	Start of clip in video time. Units: ms.
`clip_end`	INTEGER	End of clip in video time. Units: ms.

VideoDescription

Stores description information for a video associated with an activity.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Zero-based position of this part within the full description -- long descriptions are split across multiple VideoDescription records (see message_count), reassembled by concatenating each part's text in message_index order.
`message_count`	INTEGER	Total number of parts the full description is split into; message_index ranges from 0 to message_count - 1 across this description's parts.
`text`	TEXT	The video's description text.

VideoFrame

Represents a single frame in a recorded video with timestamp information.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Whole second part of the timestamp, in ISO8601 format.
`timestamp_ms`	INTEGER	Millisecond part of the timestamp.
`frame_number`	INTEGER	Number of the frame that the timestamp and timestamp_ms correlate to.

VideoTitle

Stores title information for a video associated with an activity.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Zero-based position of this part within the full title -- long titles are split across multiple VideoTitle records (see message_count), reassembled by concatenating each part's text in message_index order.
`message_count`	INTEGER	Total number of parts the full title is split into; message_index ranges from 0 to message_count - 1 across this title's parts.
`text`	TEXT	The video's title text.

WatchfaceSettings

Stores customization options for watch face layouts and styles.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`mode`	INTEGER	Display mode of the watch face.
`layout`	INTEGER	layout identifier for the watch face.
`digital_layout`	INTEGER	Layout identifier used when the watch face is in digital mode.
`analog_layout`	INTEGER	Layout identifier used when the watch face is in analog mode.

WeatherAlert

Provides warnings or advisories related to weather conditions.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	In ISO8601 format.
`report_id`	TEXT	Unique identifier from GCS report ID string, length is 12.
`issue_time`	TEXT	Time the alert was issued, in ISO8601 format.
`expire_time`	TEXT	Time the alert expires, in ISO8601 format.
`severity`	INTEGER	Warning, Watch, Advisory, Statement.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`type`	INTEGER	Tornado, Severe Thunderstorm, etc.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

WeatherConditions

Records environmental data such as temperature, wind, and humidity.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Time of update for current conditions, else forecast time, in ISO8601 format.
`weather_report`	INTEGER	Current or forecast.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`temperature`	INTEGER	temperature in degrees Celsius.
`condition`	INTEGER	Corresponds to GSC Response weatherIcon field.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`wind_direction`	INTEGER	Wind direction in degrees.
`wind_speed`	REAL	Wind speed in meters per second.
`precipitation_probability`	INTEGER	Range 0-100.
`temperature_feels_like`	INTEGER	Heat Index if GCS heatIdx above or equal to 90F or wind chill if GCS windChill below or equal to 32F. Units: C.
`relative_humidity`	INTEGER	Relative humidity, as a percentage.
`location`	TEXT	String corresponding to GCS response location string.
`observed_at_time`	TEXT	Time the conditions were observed, in ISO8601 format.
`observed_location_lat`	INTEGER	Latitude of the observed weather location, in semicircles.
`observed_location_long`	INTEGER	Longitude of the observed weather location, in semicircles.
`day_of_week`	INTEGER	Day of the week this forecast entry applies to.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`high_temperature`	INTEGER	Highest recorded temperature, in degrees Celsius.
`low_temperature`	INTEGER	Lowest recorded temperature, in degrees Celsius.

WeightScale

Weight measurement of the human standing on the Garmin Index scale.

Field	Type	Description
`file_number`	INTEGER	The file number.
`timestamp`	TEXT	Timestamp of the measurement, in ISO8601 format.
`weight`	REAL	weight measurement. Units: kg.
`percent_fat`	REAL	Body fat percentage. Units: %.
`percent_hydration`	REAL	Body hydration percentage. Units: %.
`visceral_fat_mass`	REAL	Visceral fat mass in kilograms.
`bone_mass`	REAL	Bone mass in kilograms.
`muscle_mass`	REAL	Muscle mass in kilograms.
`basal_met`	REAL	Basal metabolism. Units: kcal/day.
`physique_rating`	INTEGER	Body-composition physique rating, on the scale used by Garmin/Tanita body composition scales.
`active_met`	REAL	Active metabolism. ~4kJ per kcal, 0.25 allows max 16384 kcal.
`metabolic_age`	INTEGER	Metabolic age in years.
`visceral_fat_rating`	INTEGER	Visceral fat rating, on the scale used by Garmin/Tanita body composition scales.
`user_profile_index`	INTEGER	Associates this weight scale message to a user. This corresponds to the index of the user profile message in the weight scale file.
`bmi`	REAL	Body mass index. Units: kg/m^2.

Workout

A structured workout definition -- name, sport, capabilities, and the number of WorkoutStep records that make up its ordered sequence of steps.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.
`capabilities_id`	INTEGER	Bitmask of workout_capabilities flags describing which optional data types (such as heart rate or power) this workout includes.
`number_valid_steps`	INTEGER	Number of valid steps.
`workout_name`	TEXT	User-assigned name for this workout.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.
`pool_length`	REAL	Pool length in meters.
`pool_length_unit`	INTEGER	Unit (metric or statute) in which pool_length is expressed.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`workout_description`	TEXT	Description of the workout.

WorkoutSession

Workout_session:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`sport_id`	INTEGER	Sport-type code identifying the sport, such as running or cycling; sub_sport_id narrows this further.
`sub_sport_id`	INTEGER	Sub-sport-type code providing a more specific classification within sport_id, such as indoor cycling or trail running.
`number_valid_steps`	INTEGER	Num Valid Steps.
`first_step_index`	INTEGER	Index of the first workout_step (in the parent Workout) belonging to this session.
`pool_length`	REAL	Pool length in meters.
`pool_length_unit`	INTEGER	Unit (metric or statute) in which pool_length is expressed.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

WorkoutStep

Workout_step:.

Field	Type	Description
`file_number`	INTEGER	The file number.
`message_index`	INTEGER	Index of this record among other records of the same type in the file, used to preserve their original order.
`workout_step_name`	TEXT	Free-form name assigned to this workout step.
`duration_type`	INTEGER	How this step's duration is measured, such as by time, distance, calories, or a fixed number of repetitions.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`duration_value`	INTEGER	Raw duration value for this step; its unit depends on duration_type (see the type-specific duration_time/duration_distance/etc. fields for the decoded value).
`duration_time`	REAL	Time value for a time-based goal or alert duration, in seconds.
`duration_distance`	REAL	Distance value for a distance-based goal or alert duration, in meters.
`duration_heart_rate`	INTEGER	Heart-rate condition value for a heart-rate-based step duration. A value of 0-100 is a percentage of max heart rate; a value above 100 is bpm plus 100. Units: % or bpm.
`duration_calories`	INTEGER	Calorie value for a calories-based workout step duration, in kilocalories.
`duration_step`	INTEGER	Message_index of step to loop back to. Steps are assumed to be in the order by message_index. custom_name and intensity members are undefined for this duration type.
`duration_power`	INTEGER	Power condition value for a power-based step duration. A value of 0-1000 is a percentage of functional threshold power (FTP); a value above 1000 is watts plus 1000. Units: % or watts.
`duration_reps`	INTEGER	Number of repetitions for a reps-based step duration.
`target_type`	INTEGER	What this step's target is measured against, such as speed, heart rate, cadence, or power.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`target_value`	INTEGER	Target numeric value for this goal or workout step; its unit and meaning depend on the paired type field (such as goal_type or duration_type).
`target_speed_zone`	INTEGER	Speed zone selected as this step's target, numbered 1-10; 0 means a custom target is used instead (see custom_target_speed_low/custom_target_speed_high).
`target_heart_rate_zone`	INTEGER	Heart-rate zone selected as this step's target, numbered 1-5; 0 means a custom target is used instead (see custom_target_heart_rate_low/custom_target_heart_rate_high).
`target_cadence_zone`	INTEGER	Cadence zone selected as this step's target (valid range is device- defined, not fixed by the FIT profile); 0 means a custom target is used instead (see custom_target_cadence_low/custom_target_cadence_high).
`target_power_zone`	INTEGER	Power zone selected as this step's target, numbered 1-7; 0 means a custom target is used instead (see custom_target_power_low/custom_target_power_high).
`repeat_steps`	INTEGER	# of repetitions.
`repeat_time`	REAL	Time value for a repeated interval step, in seconds.
`repeat_distance`	REAL	Distance value for a repeated interval step, in meters.
`repeat_calories`	INTEGER	Calorie value for a repeated interval step, in kilocalories.
`repeat_heart_rate`	INTEGER	Heart-rate condition value for a heart-rate-based repeat/loop condition. A value of 0-100 is a percentage of max heart rate; a value above 100 is bpm plus 100. Units: % or bpm.
`repeat_power`	INTEGER	Power condition value for a power-based repeat/loop condition. A value of 0-1000 is a percentage of functional threshold power (FTP); a value above 1000 is watts plus 1000. Units: % or watts.
`target_stroke_type`	INTEGER	Swimming stroke type this step's target applies to.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`custom_target_value_low`	INTEGER	Raw lower-bound value for a custom target range; its unit depends on target_type (see the type-specific custom_target_speed_low/ custom_target_heart_rate_low/etc. fields for the decoded value).
`custom_target_speed_low`	REAL	Lower bound of the custom target speed range, in meters per second.
`custom_target_heart_rate_low`	INTEGER	Lower bound of a custom heart-rate target range. A value of 0-100 is a percentage of max heart rate; a value above 100 is bpm plus 100. Units: % or bpm.
`custom_target_cadence_low`	INTEGER	Lower bound of the custom target cadence range, in revolutions per minute.
`custom_target_power_low`	INTEGER	Lower bound of a custom power target range. A value of 0-1000 is a percentage of functional threshold power (FTP); a value above 1000 is watts plus 1000. Units: % or watts.
`custom_target_value_high`	INTEGER	Raw upper-bound value for a custom target range; its unit depends on target_type (see the type-specific custom_target_speed_high/ custom_target_heart_rate_high/etc. fields for the decoded value).
`custom_target_speed_high`	REAL	Upper bound of the custom target speed range, in meters per second.
`custom_target_heart_rate_high`	INTEGER	Upper bound of a custom heart-rate target range. A value of 0-100 is a percentage of max heart rate; a value above 100 is bpm plus 100. Units: % or bpm.
`custom_target_cadence_high`	INTEGER	Upper bound of the custom target cadence range, in revolutions per minute.
`custom_target_power_high`	INTEGER	Upper bound of a custom power target range. A value of 0-1000 is a percentage of functional threshold power (FTP); a value above 1000 is watts plus 1000. Units: % or watts.
`intensity`	INTEGER	Intensity classification of the workout step, such as warmup, active, rest, or cooldown.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`notes`	TEXT	Free-text notes for this workout step.
`equipment`	INTEGER	Equipment used for this workout step, such as swim fins or a paddle.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`exercise_category`	INTEGER	Raw FIT exercise-category code identifying the exercise family, such as Bench Press or Curl (see SetX's raw_category_garmin_key for its localized-name resolution).
`exercise_name`	INTEGER	Raw FIT exercise-name code identifying the specific exercise variant within its category (see SetX's raw_category_subtype_garmin_key for its localized-name resolution).
`exercise_weight`	REAL	Weight used for the exercise, in kilograms.
`weight_display_unit`	INTEGER	Unit (such as kilograms or pounds) the weight field should be displayed in.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`secondary_target_type`	INTEGER	As target_type, for this step's secondary target.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`secondary_target_value`	INTEGER	As target_value, for this step's secondary target.
`secondary_target_speed_zone`	INTEGER	Speed zone selected as this step's secondary target, numbered 1-10; 0 means a custom target is used instead (see secondary_custom_target_speed_low/secondary_custom_target_speed_high).
`secondary_target_heart_rate_zone`	INTEGER	Heart-rate zone selected as this step's secondary target, numbered 1-5; 0 means a custom target is used instead (see secondary_custom_target_heart_rate_low/secondary_custom_target_heart_rate_high).
`secondary_target_cadence_zone`	INTEGER	Cadence zone selected as this step's secondary target (valid range is device-defined, not fixed by the FIT profile); 0 means a custom target is used instead (see secondary_custom_target_cadence_low/secondary_custom_target_cadence_high).
`secondary_target_power_zone`	INTEGER	Power zone selected as this step's secondary target, numbered 1-7; 0 means a custom target is used instead (see secondary_custom_target_power_low/secondary_custom_target_power_high).
`secondary_target_stroke_type`	INTEGER	As target_stroke_type, for this step's secondary target.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`secondary_custom_target_value_low`	INTEGER	As custom_target_value_low, for this step's secondary target.
`secondary_custom_target_speed_low`	REAL	Lower bound of the secondary custom target speed range, in meters per second.
`secondary_custom_target_heart_rate_low`	INTEGER	As custom_target_heart_rate_low, for this step's secondary target. A value of 0-100 is a percentage of max heart rate; a value above 100 is bpm plus 100. Units: % or bpm.
`secondary_custom_target_cadence_low`	INTEGER	Lower bound of the secondary custom target cadence range, in revolutions per minute.
`secondary_custom_target_power_low`	INTEGER	As custom_target_power_low, for this step's secondary target. A value of 0-1000 is a percentage of functional threshold power (FTP); a value above 1000 is watts plus 1000. Units: % or watts.
`secondary_custom_target_value_high`	INTEGER	As custom_target_value_high, for this step's secondary target.
`secondary_custom_target_speed_high`	REAL	Upper bound of the secondary custom target speed range, in meters per second.
`secondary_custom_target_heart_rate_high`	INTEGER	As custom_target_heart_rate_high, for this step's secondary target. A value of 0-100 is a percentage of max heart rate; a value above 100 is bpm plus 100. Units: % or bpm.
`secondary_custom_target_cadence_high`	INTEGER	Upper bound of the secondary custom target cadence range, in revolutions per minute.
`secondary_custom_target_power_high`	INTEGER	As custom_target_power_high, for this step's secondary target. A value of 0-1000 is a percentage of functional threshold power (FTP); a value above 1000 is watts plus 1000. Units: % or watts.

ZonesTarget

Defines target zones for heart rate and power during workouts.

Field	Type	Description
`file_number`	INTEGER	The file number.
`max_heart_rate`	INTEGER	Maximum heart rate used as the basis for computing heart-rate zones, in beats per minute.
`threshold_heart_rate`	INTEGER	Heart-rate threshold (LTHR) used as the basis for computing heart-rate zones via the percent-of-threshold method.
`functional_threshold_power`	INTEGER	Functional threshold power (FTP) used as the basis for computing power zones, in watts.
`heart_rate_calc_type`	INTEGER	FIT heart-rate-zone calculation method, such as percent of max heart rate or percent of heart rate reserve.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.
`pwr_calc_type`	INTEGER	Power Calc Type.The localized text equivalent of this value can be obtained by lookup into better_labels_lookup.

For this same schema as executable SQL rather than prose, see The schema as SQL.

Data Dictionary, Full Field Reference

See also

Tables

AadAccelFeatures

AccelerometerData

Activity

AntChannelId

AntRx

AntTx

AviationAttitude

BarometerData

BeatIntervals

BikeProfile

BloodPressure

CadenceZone

CameraEvent

Capabilities

ChronoShotData

ChronoShotSession

ClimbPro

Connectivity

Course

CoursePoint

DeveloperCIQFields

DeveloperDataId

DeviceAuxBatteryInfo

DeviceInfo

DeviceSettings

DiveAlarm

DiveApneaAlarm

DiveGas

DiveSettings

DiveSummary

Event

ExdDataConceptConfiguration

ExdDataFieldConfiguration

ExdScreenConfiguration

ExerciseTitle

FieldCapabilities

FieldDescription

FileCapabilities

FileCreator

FileID

Goal

GpsMetadata

GyroscopeData

Hr

HrmProfile

Hrv

HrvStatusSummary

HrvValue

HrZone

HsaAccelerometerData

HsaBodyBatteryData

HsaConfigurationData

HsaEvent

HsaGyroscopeData

HsaHeartRateData

HsaRespirationData

HsaSpo2Data

HsaStepData

HsaStressData

HsaWristTemperatureData

Jump

Lap

Length

MagnetometerData

MaxMetData

MemoGlob

MesgCapabilities

MetZone

Monitoring

MonitoringHrData

MonitoringInfo

NapEvent

NmeaSentence

ObdiiData

OhrSettings

OneDSensorCalibration

PowerZone
